选择PDNSPTOC1操作NSPTOC2操作CBXCBR1
INTRPTEF1操作
或
或
LED11（AR进行中）
X110
6.
7.
X120_BI3（断路器开路）
BI4（CB弹簧充电）
DARREC1
0 -> 1
79初始化_1初始化_ 2初始化u3初始化单元4初始化 5初始化U6 DEL_INIT_2 DEL_ INIT _3 delUinitu4 BLK_RECL_T BLK_ RCLM_T BLK_THERM CB_POS CB_ READY INC_SHOTP INHIBIT_RECR_ON SYNC
OPEN_CB CLOSE_CB CMD_WAIT INPRO LOCKED PROT_CRD UNSC_RECL AR_ON READY
弧弧1
弧（1）
50L/50NL（1）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
弧弧2
弧（2）
50L/50NL（2）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
弧弧3
弧（3）
50L/50NL（3）3I
Io
块REM_FLT_ARC OPR_MODE
操作ARC_FLT_DET
A071338 V7 EN
图50：电弧保护
电弧保护（ARCSARC1…3）和自动重合闸（DARREC1）包括在：
可选功能。
第3节1MRS756378 K
REF615标准配置
102参考文献615
应用手册
电弧保护为三个电弧传感器提供单独的功能块，可以：
连接到IED。每个电弧保护功能块有两个不同的
运行模式，带或不带相位和剩余电流检查。运转
来自电弧保护功能块的信号连接到主跳闸
并且还连接到报警LED 10作为公共操作指示。
自动重合闸被配置为通过来自多个
通过INIT1…5输入的保护级。可以创建个人
每个输入的自动关闭序列。
自动重合闸功能可通过INHIBIT_RECL输入被阻断。通过
默认情况下，所选保护功能的操作连接到此输入。A.
对本地或远程断路器的控制命令也会阻止
通过CBXCBR选择信号自动重合闸功能。
自动重合闸序列的断路器可用性表示为：
DARREC1中的CB_READY输入。在配置中，该信号未连接
到任何二进制输入。因此，该功能假设断路器为
随时可用。
正在进行的自动重合闸序列指示连接到报警LED 11。
1MRS756378 K第3节
REF615标准配置
参考文献615-103
应用手册
3.8.3.2干扰记录器和跳闸电路监控功能图
LED7（DR触发）
或
INTRPTEF1操作EFHPTOC1操作PDNSPTOC1操作T1PTTR1操作INRPHAR1-blk2h或
PHLPTOC1运行PHHPTOC1运行PHHPTOC2运行PHIPTOC1运行NSPTOC1运行NSPTOC运行
或
DEFLPDEF1操作DEFLPDEF2操作DEFHPDEF1操作EFPADM1操作EFPADM2操作EFPADM3操作或
WPWDE3操作或
或
ROVPTOV1操作WPWDE2操作WPWDE1操作ROVPTOV2操作ROVPTOV3操作或
ARCSARC1-arc_flt_det
ARCSARC2-arc_flt_det
ARCSARC3-arc_flt_det
ARCSARC1运行ARCSARC2运行ARCSARC3运行DARREC inpro
干扰记录器
GUID-4BE45287-D708-41F3-851A-084A9AC3265E V3 EN
图51：干扰记录器
来自保护级的所有启动和运行信号均路由至触发器
干扰记录器或由干扰记录器记录，取决于
在参数设置上。此外，所选自动重合闸、ARC
保护信号和来自X1的三个二进制输入 ABB 系统模块备件1MRK000005-520 1MRK002133-ABR02 顺丰包邮
 ABB 系统模块备件1MRK000005-520 1MRK002133-ABR02 顺丰包邮
PDNSPTOC1-operate NSPTOC1-operate NSPTOC2-operate CBXCBR1-selected
INTRPTEF1-operate
OR
OR
LED11 (AR IN PROGRESS)
X110
6
7
X120_BI3 (CB Open)
BI4 (CB Spring Charged)
DARREC1
0 -> 1
79 INIT_1 INIT_2 INIT_3 INIT_4 INIT_5 INIT_6 DEL_INIT_2 DEL_INIT_3 DEL_INIT_4 BLK_RECL_T BLK_RCLM_T BLK_THERM CB_POS CB_READY INC_SHOTP INHIBIT_RECL RECL_ON SYNC
OPEN_CB CLOSE_CB CMD_WAIT INPRO LOCKED PROT_CRD UNSUC_RECL AR_ON READY
ARCSARC1
ARC (1)
50L/50NL (1) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
ARCSARC2
ARC (2)
50L/50NL (2) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
ARCSARC3
ARC (3)
50L/50NL (3) 3I
Io
BLOCK REM_FLT_ARC OPR_MODE
OPERATE ARC_FLT_DET
A071338 V7 EN
Figure 50: Arc protection
Arc protection (ARCSARC1...3) and autoreclosing (DARREC1) are included as
optional functions.
Section 3 1MRS756378 K
REF615 standard configurations
102 REF615
Application Manual
The arc protection offers individual function blocks for three arc sensors that can
be connected to the IED. Each arc protection function block has two different
operation modes, with or without the phase and residual current check. Operate
signals from the arc protection function blocks are connected to the Master Trip
and also to the alarm LED 10 as a common operate indication.
The autorecloser is configured to be initiated by operate signals from a number of
protection stages through the INIT1...5 inputs. It is possible to create individual
autoreclose sequences for each input.
The autoreclose function can be blocked with the INHIBIT_RECL input. By
default, the operation of selected protection functions are connected to this input. A
control command to the circuit breaker, either local or remote, also blocks the
autoreclose function via the CBXCBR-selected signal.
The circuit breaker availability for the autoreclosure sequence is expressed with the
CB_READY input in DARREC1. In the configuration, this signal is not connected
to any of the binary inputs. As a result, the function assumes that the breaker is
available all the time.
The autoreclose sequence in progress indication is connected to the alarm LED 11.
1MRS756378 K Section 3
REF615 standard configurations
REF615 103
Application Manual
3.8.3.2 Functional diagram for disturbance recorder and trip circuit supervision
LED7 (DR TRIGGERING)
OR
INTRPTEF1-operate EFHPTOC1-operate PDNSPTOC1-operate T1PTTR1-operate INRPHAR1-blk2h OR
PHLPTOC1-operate PHHPTOC1-operate PHHPTOC2-operate PHIPTOC1-operate NSPTOC1-operate NSPTOC2-operate
OR
DEFLPDEF1-operate DEFLPDEF2-operate DEFHPDEF1-operate EFPADM1-operate EFPADM2-operate EFPADM3-operate OR
WPWDE3-operate OR
OR
ROVPTOV1-operate WPWDE2-operate WPWDE1-operate ROVPTOV2-operate ROVPTOV3-operate OR
ARCSARC1-arc_flt_det
ARCSARC2-arc_flt_det
ARCSARC3-arc_flt_det
ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate DARREC-inpro
DISTURBANCE RECORDER
GUID-4BE45287-D708-41F3-851A-084A9AC3265E V3 EN
Figure 51: Disturbance recorder
All start and operate signals from the protection stages are routed either to trigger
the disturbance recorder or to be recorded by the disturbance recorder, depending
on the parameter settings. Additionally, the selected autorecloser, the ARC
protection signals and the three binary inputs from X1 | ABB 系统模块备件1MRK000005-520 1MRK002133-ABR02 顺丰包邮 | | | |
