包括两个独立的跳闸电路监控功能，用于PO3的TCSCBR1
（X100:15-19）和用于PO4的TCSCBr2（X100:20-24）。两个功能都被阻止
通过主跳闸（TRPPTRC1和TRPPTRC2）和断路器断开
信号TCS报警指示连接至LED 9。
默认情况下，预期中没有外部电阻器
断路器跳闸线圈电路与电路并联
断路器常开辅助触点。
保险丝故障监控SEQRFUF1检测电压测量中的故障
电路。检测到故障，如打开的微型断路器，并且
报警连接至报警LED 9。
电流测量电路中的故障由CCRDIF检测。当失败是
检测到，电流保护功能中的闭锁信号被激活
测量计算的序列分量电流和不必要的操作可能
避免。报警信号连接到报警LED 9。
1MRS756378 K第3节
REF615标准配置
参考文献615105
应用手册
3.8.3.3控制和联锁功能图
PHLPTOC1运行PHHPTOC1运行PHHPTOC2运行PHIPTOC1运行NSPTOC1运行NSPTOC运行
PDNSPTOC1运行DEFLPDEF1运行EFHPTOC1运行+
X100
16
17
15
18
或
主跳闸#1
开路断路器/
跳闸线圈1 PO3 TRPPTRC1块操作RST_LKOUT
带锁定模式选择的跳闸CL_LKOUT
TRPPTRC2块操作RST_LKOUT
带锁定模式选择的跳闸CL_LKOUT
DARREC1开路断路器
CBXCBR1-exe_op
主跳闸#2
TCS1
或
19
+
X100
22
21
23
PO4
TCS2 24
20
DEFLPDEF2操作DEFHPDEF1操作EFPADM1操作EFPADM2操作EFPADM3操作INTRPTEF1操作ROVPTOV1操作ROVPTOV3操作ROVPTOV2操作ARCSARC1操作ARCSARC2操作ARCSARC3操作
PHLPTOC1运行PHHPTOC1运行PHHPTOC2运行PHIPTOC1运行NSPTOC1运行NSPTOC运行
PDNSPTOC1操作DEFLPDEF1操作EFHPTOC1操作或
DEFLPDEF2操作DEFHPDEF1操作EFPADM1操作EFPADM2操作EFPADM3操作INTRPTEF1操作ROVPTOV1操作ROVPTOV3操作ROVPTOV2操作ARCSARC1操作ARCSARC2操作ARCSARC3操作CCBRBRF1 trret
WPWDE1操作WPWDE2操作WPWDE3操作
WPWDE1操作WPWDE2操作WPWDE3操作
开路断路器/
跳闸线圈2
BI4（锁定复位）
GUID-4963C315-60C2-4C60-BE7F-B18D87A8D35E V3 EN
图53：主跳闸
来自保护装置的操作信号连接至双跳闸输出
通过相应的主设备联系PO3（X100:15-19）和PO4（X100:20-24）
跳闸TRPPTRC1和TRPPTRC2。断路器的断开控制命令
从本地或远程CBXCBR1-exe_op或自动重合闸器DARREC1-
open_ cb直接连接到输出PO3（X100:15-19）。
TRPPTRC1和2提供锁定/闭锁功能、事件生成和
跳闸信号持续时间设置。如果选择了锁定操作模式，则一个二进制
输入可重新分配给主跳闸的RST_LKOUT输入，以启用
带有按钮的外部重置。
第3节1MRS756378 K
REF615标准配置
106参考文献615
应用手册
GUID-4DED29226-A92A-4F6A-BCAA-7D9CD24ACFC8 V3 EN
图54：断路器控制
有两种类型的隔离开关和接地开关块可用。
DCSXSWI1…3和ESSSWI1…2仅为状态类型，而DCXSWI1…2和
ESXSWI1为可控型。默认情况下，仅连接状态块
标准配置逻辑。如果选可控操作，则可控
可以使用隔离开关和接地开关块的类型，而不是状态
这是的类型。可以完成控制块的连接和配置
使用PCM600。
附加卡X110的二进制输入5和6用于母线
隔离开关（DCSXSWI1）或断路器支架位置指示。
表37：二进制输入5和6表示的设备位置
待通电的一次设备位置输入
输入5（X110:8-9）输入6（X110:10-9）
母线隔离开关闭合x
母线隔离开关断开x
断路器台车处于工作位置x
断路器台车处于测试位置x
1MRS756378 K第3节
REF615标准配置
参考文献615-107
应用手册
二进制输入7和8（X110:11-13）用于以下位置指示：
线路侧接地开关。
当ENA_CLOSE输入激活时，断路器闭合被启用。
输入可由配置逻辑激活，配置逻辑是
隔离开关或断路器支架和接地开关位置状态以及状态
主跳闸逻辑、气压报警和断路器弹簧充电。
DCSXSWI的OKPOS输出定义了隔离开关或断路器卡车是否：
对打开（测试位置）或关闭（维修位置）。这个，一起
在接地开关断开和非激活跳闸信号的情况下，激活闭合启用
向断路器控制功能块发送信号。开放操作始终是
启用。自动重合闸闭合命令信号直接连接 ABB 81ET10C GJR2338700R0001 供应DCS/PLC控制系统应用
 ABB 81ET10C GJR2338700R0001 供应DCS/PLC控制系统应用
Two separate trip circuit supervision functions are included, TCSSCBR1 for PO3
(X100:15-19) and TCSSCBR2 for PO4 (X100:20-24). Both functions are blocked
by the Master Trip (TRPPTRC1 and TRPPTRC2) and the circuit breaker open
signal. The TCS alarm indication is connected to LED 9.
By default it is expected that there is no external resistor in the
circuit breaker tripping coil circuit connected parallel with circuit
breaker normally open auxiliary contact.
The fuse failure supervision SEQRFUF1 detects failures in voltage measurement
circuits. Failures, such as an open miniature circuit breaker, are detected and the
alarm is connected to the alarm LED 9.
Failures in current measuring circuits are detected by CCRDIF. When a failure is
detected, blocking signal is activated in current protection functions that are
measuring calculated sequence component currents, and unnecessary operation can
be avoided. The alarm signal is connected to the alarm LED 9.
1MRS756378 K Section 3
REF615 standard configurations
REF615 105
Application Manual
3.8.3.3 Functional diagrams for control and interlocking
PHLPTOC1-operate PHHPTOC1-operate PHHPTOC2-operate PHIPTOC1-operate NSPTOC1-operate NSPTOC2-operate
PDNSPTOC1-operate DEFLPDEF1-operate EFHPTOC1-operate +
X100
16
17
15
18
OR
MASTER TRIP #1
Open CB /
trip coil 1 PO3 TRPPTRC1 BLOCK OPERATE RST_LKOUT
TRIP CL_LKOUT With lock-out mode selection
TRPPTRC2 BLOCK OPERATE RST_LKOUT
TRIP CL_LKOUT With lock-out mode selection
DARREC1-open cb
CBXCBR1-exe_op
MASTER TRIP #2
TCS1
OR
19
+
X100
22
21
23
PO4
TCS2 24
20
DEFLPDEF2-operate DEFHPDEF1-operate EFPADM1-operate EFPADM2-operate EFPADM3-operate INTRPTEF1-operate ROVPTOV1-operate ROVPTOV3-operate ROVPTOV2-operate ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate
PHLPTOC1-operate PHHPTOC1-operate PHHPTOC2-operate PHIPTOC1-operate NSPTOC1-operate NSPTOC2-operate
PDNSPTOC1-operate DEFLPDEF1-operate EFHPTOC1-operate OR
DEFLPDEF2-operate DEFHPDEF1-operate EFPADM1-operate EFPADM2-operate EFPADM3-operate INTRPTEF1-operate ROVPTOV1-operate ROVPTOV3-operate ROVPTOV2-operate ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate CCBRBRF1-trret
WPWDE1-operate WPWDE2-operate WPWDE3-operate
WPWDE1-operate WPWDE2-operate WPWDE3-operate
Open CB /
trip coil 2
BI4 (Lock-out reset)
GUID-4963C315-60C2-4C60-BE7F-B18D87A8D35E V3 EN
Figure 53: Master trip
The operate signals from the protections are connected to the two trip output
contacts PO3 (X100:15-19) and PO4 (X100:20-24) via the corresponding Master
Trips TRPPTRC1 and TRPPTRC2. Open control commands to the circuit breaker
from local or remote CBXCBR1-exe_op or from the auto-recloser DARREC1-
open_cb are connected directly to the output PO3 (X100:15-19).
TRPPTRC1 and 2 provide the lockout/latching function, event generation and the
trip signal duration setting. If the lockout operation mode is selected, one binary
input can be reassigned to the RST_LKOUT input of the Master Trip to enable
external reset with a push button.
Section 3 1MRS756378 K
REF615 standard configurations
106 REF615
Application Manual
GUID-4DED2926-A92A-4F6A-BCAA-7D9CD24ACFC8 V3 EN
Figure 54: Circuit breaker control
There are two types of disconnector and earthing switch blocks available.
DCSXSWI1...3 and ESSXSWI1...2 are status only type, and DCXSWI1...2 and
ESXSWI1 are controllable type. By default, the status only blocks are connected in
standard configuration logic. If controllable operation is preferred, the controllable
type of disconnector and earthing switch blocks can be used instead of the status
only type. The connection and configuration of the control blocks can be done
using PCM600.
The binary inputs 5 and 6 of the additional card X110 are used for busbar
disconnector (DCSXSWI1) or circuit-breaker truck position indication.
Table 37: Device positions indicated by binary inputs 5 and 6
Primary device position Input to be energized
Input 5 (X110:8-9) Input 6 (X110:10-9)
Busbar disconnector closed x
Busbar disconnector open x
Circuit breaker truck in service position x
Circuit breaker truck in test position x
1MRS756378 K Section 3
REF615 standard configurations
REF615 107
Application Manual
The binary inputs 7 and 8 (X110:11-13) are designed for the position indication of
the line-side earth switch.
The circuit breaker closing is enabled when the ENA_CLOSE input is activated.
The input can be activated by the configuration logic, which is a combination of
the disconnector or breaker truck and earth-switch position statuses and the statuses
of the master trip logics and gas pressure alarm and circuit-breaker spring charging.
The OKPOS output from DCSXSWI defines if the disconnector or breaker truck is
definitely either open (in test position) or close (in service position). This, together
with the open earth-switch and non-active trip signals, activates the close-enable
signal to the circuit breaker control function block. The open operation is always
enabled. The auto-recloser close command signals are directly connected to the
output contact PO1 (X100:6-7).
The ITL_BYPASS input can be used, for example, to always enable the closing of
the circuit breaker when the circuit breaker truck is in the test position, despite of
the interlocking conditions being active when the circuit breaker truck is closed in
service position.
If the ENA_CLOSE and BLK_CLOSE signals are completely
removed from the breaker control function block CBXCBR with
PCM600, the function assumes that the breaker close commands
are allowed continuously | ABB 81ET10C GJR2338700R0001 供应DCS/PLC控制系统应用 | | | |
