C是定时器，用于设置输出的小脉冲长度。
IED中有四个通用定时器（TPGAPC1..4）。剩下的
功能图中未描述的功能可在PCM600中用于：
连接（如适用）。
3.9标准配置F
3.9.1应用
定向过电流和定向接地故障的标准配置
相电压测量、欠压和过压保护
保护主要用于综合保护和控制
断路器控制异步电动机的功能。未成年人
修改：该标准配置也适用于接触器
由电机控制。该配置还包括根据导纳、功率或谐波原理选择接地故障保护的附加选项。
默认情况下，具有标准配置的IED从工厂交付
设置和参数。终端用户在传入、传出和
IED内的内部信号指定使该配置更进一步
适用于不同的主电路布局和相关功能需求
使用PCM600修改内部功能。
3.9.2功能
表38：标准配置F中包含的功能
功能IEC 61850 IEC 60617 IEC-ANSI
保护
三相无方向过电流
保护，瞬时级，实例1 PHIPTOC1 3I>>>（1）50P/51P（1）
三相方向过电流保护，
低级，例如1 DPHLPDOC1 3I>->（1）67-1（1）
三相方向过电流保护，
低级，例如2 DPHLPDOC2 3I>->（2）67-1（2）
三相方向过电流保护，
级DPHHPDOC1 3I>>->67-2
下一页续表
第3节1MRS756378 K
REF615标准配置
110参考文献615
应用手册
功能IEC 61850 IEC 60617 IEC-ANSI
定向接地故障保护，低级，
实例1 DEFLPDEF1 Io>->（1）67N-1（1）
定向接地故障保护，低级，
实例2 DEFLPDEF2 Io>->（2）67N-1（2）
定向接地故障保护，级DEFHPDEF1 Io>->67N-2
基于导纳的接地故障保护，
实例1 EFPADM1 Yo>->（1）21YN（1）
基于导纳的接地故障保护，
实例2 EFPADM2 Yo>->（2）21YN（2）
基于导纳的接地故障保护，
实例3 EFPADM3 Yo>->（3）21YN（3）
基于瓦特计的接地故障保护，
实例1 WPWDE1 Po>->（1）32N（1）
基于瓦特计的接地故障保护，
实例2 WPWDE2 Po>->（2）32N（2）
基于瓦特计的接地故障保护，
实例3 WPWDE3 Po>->（3）32N（3）
瞬态/间歇性接地故障保护INTRPTEF1 Io>->IEF 67NIEF
谐波接地故障保护HAEFPTOC1 Io>HA 51NHA
非定向（越野）接地故障
保护，使用计算Io EFHPTOC1 Io>>（1）51N-2（1）
负序过电流保护，
实例1 NSPTOC1 I2>（1）46（1）
负序过电流保护，
实例2 NSPTOC2 I2>（2）46（2）
相位不连续保护PDNSPTOC1 I2/I1＞46PD
剩余过电压保护，例如1 ROVPTOV1 Uo>（1）59G（1）
剩余过电压保护，例如2 ROVPTOV2 Uo>（2）59G（2）
剩余过电压保护，例如3 ROVPTOV3 Uo>（3）59G（3）
例如，三相欠压保护
1.
PHPTUV1 3U<（1）27（1）
例如，三相欠压保护
2.
PHPTUV2 3U<（2）27（2）
例如，三相欠压保护
3.
PHPTUV3 3U<（3）27（3）
三相过电压保护，例如1 PHPTOV1 3U>（1）59（1）
三相过电压保护，例如2 PHPTOV2 3U>（2）59（2）
三相过电压保护，例如3 PHPTOV3 3U>（3）59（3）
正序欠压保护，
实例1 PSPTUV1 U1<（1）47U+（1）
负序过电压保护，
实例1 NSPTOV1 U2>（1）47O-（1）
馈线的三相热保护，
电缆和配电变压器T1PTTR1 3th>F 49F
断路器故障保护CCBRBRF1 3I>/Io>BF 51BF/51NBF
三相涌流检测器INRPHAR1 3I2f>68
下一页续表
1MRS756378 K第3节
REF615标准配置
参考文献615111
应用手册
功能IEC 61850 IEC 60617 IEC-ANSI
主跳闸，实例1 TRPPTRC1主跳闸（1）94/86（1）
主跳闸，实例2 TRPPTRC2主跳闸（2）94/86（2）
电弧保护，实例1电弧电弧1电弧（1）50L/50NL（1）
电弧保护，实例2电弧2电弧（2）50L/50NL（2）
电弧保护，例如3弧电弧3弧（3）50L/50NL（3）
控制
断路器控制CBXCBR1 I<->O断路器I<->O断路器
隔离开关控制，例如1 DCXSWI1 I<->O DCC
(1)
I<->O DCC
(1)
隔离开关控制，实例2 DCXSWI2 I<->O DCC
(2)
I<->O DCC
(2)
接地开关控制ESXSWI1 I<->O ESC I<->O ESC
隔离开关位置指示，例如1 DCSXSWI1 I<->O DC（1）I<->O DC（2）
隔离开关位置指示，例如2 DCSXSWI2 I<->O DC（2）I<->O DC（1）
