功能图详细描述了IED的保护功能，以及
想象工厂设置的默认连接。
四个过电流级可用于过电流和短路保护。
其中三个包括方向功能（DPHxPDOC）。非定向
瞬时级（PHIPTOC1）可通过向二进制输入1通电来阻止
（X120:1-2）。两个负序过电流级（NSPTOC1和
NSPTOC2）可用于相位不平衡保护。涌流检测
块的（INRPHAR1）输出BLK2H启用功能块或
乘以任何所示保护功能块的有效设置。
GUID-F0BE506C-0A96-4AA2-AC55-FFD9BCD23951 V2 EN
图56：定向过电流保护
所有操作信号均连接至主跳闸和报警LED。LED 1
用于过电流，LED 4用于负序过电流保护
操作指示。LED 4也用于相位不连续保护操作
指示
1MRS756378 K第3节
REF615标准配置
参考文献615115
应用手册
从方向过电流第二低开始的上游阻塞
级（DPHLPDOC2）连接到输出SO1（X110:14-16）。这个输出是
用于向相关过电流保护级发送闭锁信号
进料舱的简易爆炸装置。
闭塞启动操作
双人（越野）
接地故障保护
定向接地故障
保护
间歇性接地故障
保护
瓦特计接地故障
保护（可选）
接地故障导纳
保护（可选）
谐波接地故障
保护（可选）
GUID-F82FE8A6-6AA1-44D9-8FE2-8B2C51CEA7AA V3 EN
图57：定向接地故障保护
提供三级定向接地故障保护。根据
命令代码，方向接地故障保护方法可基于
仅常规定向接地故障（DEFxPDEF）或同时发生
具有导纳标准（EFPADM）或功率计接地故障保护（WPWDE）
或基于谐波的接地故障保护（HAEFPTOC）。此外，还有
用于瞬态接地故障的专用保护级（INTRPTEF）
补偿网络中的电缆间歇性接地故障保护。
第3节1MRS756378 K
REF615标准配置
116参考文献615
应用手册
专用非定向接地故障保护块（EFHPTOC）旨在：
用于在隔离或补偿的情况下防止双接地故障
网络。该保护功能使用计算的剩余电流源
从相电流。
二进制输入2（X110:3-4）用于定向接地故障保护
模块继电器特性角（RCA:0°/-90°）或运行模式（I0Sinφ/
φ）的变化。所有操作信号均连接至主跳闸装置以及
报警LED 2。
DPHHPDOC1操作DPHLPDOC2操作PHIPTOC1操作DEFLPDEF2操作DEFHPDEF1操作或
X120_BI2（CB闭合）+PO2
8.
9
X100
LED6（CBFP操作）
上游断路器CCBRBRF1的CBFP跳闸
3I>/Io->BF
51BF/51NBF 3I
Io
启动POSCLOSE CB_FAULT块
TRRET TRBU CB_FAULT_AL
PDNSTOC1
I2/I1
46PD 3I
闭塞启动操作
T1PTTR1
3 >
49F 3I
BLK_OPR ENA_MULT
操作报警BLK_CLOSE START
热过载保护
相位不连续保护
断路器故障保护
LED5（过载报警）
LED4（NPS/PD运行）
WPWDE2运行WPWDE3运行电弧ARC1运行电弧ARC2运行电弧ARC3运行
CCRDIF_FAIL
EFPADM2运行EFPADM3运行
GUID-5F0B30AD-0B3F-4B6D-BFAC-7209FA9DAACD V3 EN
图58：相位不连续、热过载和断路器故障
保护
相位不连续性保护（PDNPSTOC1）提供以下保护：
正常三相负载供电中断，例如，在停机时
指挥情况。相位不连续保护的操作信号为：
连接到主跳闸，也连接到报警LED和干扰
录音机热过载保护（T1PTTR1）提供以下指示：
超载情况。热过载保护的操作信号为：
连接到主跳闸和报警LED。LED 4用于
相位不连续保护操作指示，与负极相同
顺序过电流保护操作指示，LED 5用于
热过载保护报警指示。
断路器故障保护（CCBRBRF1）通过启动输入启动
IED中不同保护级的数量。断路器故障保护 ABB 5SXE04-0146 3BHE004569R0003 5SHZ0860F0005 励磁系统控制
 ABB 5SXE04-0146 3BHE004569R0003 5SHZ0860F0005 励磁系统控制
nctional diagrams describe the IED’s protection functionality in detail and
picture the factory set default connections.
Four overcurrent stages are available for overcurrent and short-circuit protection.
Three of them include directional functionality (DPHxPDOC). The non-directional
instantaneous stage (PHIPTOC1) can be blocked by energizing the binary input 1
(X120:1-2). Two negative-sequence overcurrent stages (NSPTOC1 and
NSPTOC2) are available for phase unbalance protection. The inrush detection
block’s (INRPHAR1) output BLK2H enables either blocking the function or
multiplying the active settings for any of the shown protection function blocks.
GUID-F0BE506C-0A96-4AA2-AC55-FFD9BCD23951 V2 EN
Figure 56: Directional overcurrent protection
All operate signals are connected to the Master Trip and to the alarm LEDs. LED 1
is used for overcurrent and LED 4 for negative-sequence overcurrent protection
operate indication. LED 4 is also used for phase discontinuity protection operate
indication.
1MRS756378 K Section 3
REF615 standard configurations
REF615 115
Application Manual
The upstream blocking from the start of the directional overcurrent second low
stage (DPHLPDOC2) is connected to the output SO1 (X110:14-16). This output is
used for sending a blocking signal to the relevant overcurrent protection stage of
the IED at the infeeding bay.
BLOCK START OPERATE
DOUBLE (CROSS-COUNTRY)
EARTH-FAULT PROTECTION
DIRECTIONAL EARTH-FAULT
PROTECTION
INTERMITTENT EARTH-FAULT
PROTECTION
WATTMETRIC EARTH-FAULT
PROTECTION (Optional)
ADMITTANCE EARTH-FAULT
PROTECTION (Optional)
HARMONIC EARTH-FAULT
PROTECTION (Optional)
GUID-F82FE8A6-6AA1-44D9-8FE2-8B2C51CEA7AA V3 EN
Figure 57: Directional earth-fault protection
Three stages are offered for directional earth-fault protection. According to the
order code, the directional earth-fault protection method can be based on
conventional directional earth-fault (DEFxPDEF) only or alternatively together
with admittance criteria (EFPADM) or wattmetric earth-fault protection (WPWDE)
or harmonic based earth-fault protection (HAEFPTOC). In addition, there is a
dedicated protection stage (INTRPTEF) either for transient-based earth-fault
protection or for cable intermittent earth-fault protection in compensated networks.
Section 3 1MRS756378 K
REF615 standard configurations
116 REF615
Application Manual
A dedicated non-directional earth-fault protection block (EFHPTOC) is intended
for protection against double earth-fault situations in isolated or compensated
networks. This protection function uses the calculated residual current originating
from the phase currents.
The binary input 2 (X110:3-4) is intended for directional earth-fault protection
blocks’ relay characteristic angle (RCA: 0°/-90°) or operation mode (I0Sinφ/
I0Cosφ) change. All operate signals are connected to the Master Trip as well as to
the alarm LED 2.
DPHHPDOC1-operate DPHLPDOC2-operate PHIPTOC1-operate DEFLPDEF2-operate DEFHPDEF1-operate OR
X120_BI2 (CB Closed) + PO2
8
9
X100
LED6 (CBFP OPERATE)
CBFP trip to upstream breaker CCBRBRF1
3I>/Io -> BF
51BF/51NBF 3I
Io
START POSCLOSE CB_FAULT BLOCK
TRRET TRBU CB_FAULT_AL
PDNSTOC1
I2 / I1
46PD 3I
BLOCK START OPERATE
T1PTTR1
3 >
49F 3I
BLK_OPR ENA_MULT
OPERATE ALARM BLK_CLOSE START
THERMAL OVERLOAD PROTECTION
PHASE DISCONTINUITY PROTECTION
BREAKER FAILURE PROTECTION
LED5 (OVERLOAD ALARM)
LED4 (NPS/PD OPERATE)
WPWDE2-operate WPWDE3-operate ARCSARC1-operate ARCSARC2-operate ARCSARC3-operate
CCRDIF_FAIL
EFPADM2-operate EFPADM3-operate
GUID-5F0B30AD-0B3F-4B6D-BFAC-7209FA9DAACD V3 EN
Figure 58: Phase discontinuity, thermal overload and circuit breaker failure
protection
The phase discontinuity protection (PDNPSTOC1) provides protection for
interruptions in the normal three-phase load supply, for example, in downed
conductor situations. The operate signal of the phase discontinuity protection is
connected to the Master Trip and also to an alarm LED and the disturbance
recorder. The thermal overload protection (T1PTTR1) provides indication on
overload situations ABB 5SXE04-0146 3BHE004569R0003 5SHZ0860F0005 励磁系统控制
| | | |
