two valid connection possibilities:
• Single power source (SD8xx or SS8xx) for the processor units and the BC820s
on both the segments (say, segments A and B). See Figure 38 on page 115.
• One power source (SD8xx or SS8xx) for the processor unit on segment A and
the BC820 on segment B, and another power source (SD8xx or SS8xx) for the
processor unit on segment B and the BC820 on segment A. See Figure 39 on
page 116.
The maximum number of CEX-Bus units connected to a BC820 is six. The
primary function of BC820 is to divide the CEX-Bus into two physically separate
segments for increased system availability, a faulty CEX-Bus unit on one segment
will not affect the processor unit or the other CEX-Bus segment. It is also
important to note that when using the BC820 together with redundant CEX-Bus
units these units shall be mounted on different BC820 CEX-Bus segments.
Do not connect the two CEX-Bus segments, separated with BC820, to each other
with CEX-Bus extension cable TK850.
For obtaining redundant power supply, connect the external connector to the
SS82x voting device. For details of SS82x connections, see Installing the
SS823/SS832 Voting Unit on page 145. See also Powering from an External
Source on page 183.
Section 2 Installation Installing the CEX-Bus Interconnection Unit BC820/TP850
3BSE036351-600 A 111
The BC820 CEX-Bus Interconnection Unit, offers a way to section the CEX-Bus
into two independent segments. This improves availability in systems with
redundant communication interfaces. Figure 35 on page 111 shows a configuration
example. The base plate has a preset, two letter Alpha code lock to prevent the
installation of an incorrect type of unit onto the TP850 base plate.
The BC820 is powered from the processor unit via the CEX-Bus and can also
support the CEX-Bus with redundant power through its external connector for
power supply.
BC820 transmits the RCU-Link and extends the CEX-Bus and RCU-Link cable
length up to 200 m. The number of CEX-Bus interfaces is limited to 6 with each
BC820.
It is not allowed to manipulate CEX bus base plates in a powered and running
system. Before changing or removing a base plate, all CEX modules on that
segment must be removed.
BC820 can only be used with PM858, PM862, PM866 (PR:F or later, which
corresponds to PR:H or later for PM866K01), PM866A
Figure 35. Redundant Communication Interface Units and Controllers
Installing the CEX-Bus Interconnection Unit BC820/TP850 Section 2 Installation
112 3BSE036351-600 A
The BC820 unit can be set in two different states, called upper or lower. Note that
the two units in a pair never are allowed to be set to the same state. i.e. one shall be
set to lower and the other to upper. The reason for that is to support functions in role
selection, primary and secondary, between the controller CPUs. A toggle switch
selects the state, see Figure 36.
Hot swap of the BC820 located next to a primary or single controller CPU,
otherwise called “direct BC820”, might jeopardize the whole controller and
should not be performed unless every module on the CEX-Bus are in a
non-operating state.
Hot swap of the BC820 is not located next to a primary or single controller CPU,
if located then “indirect BC820”, will shut down and non-redundant interface
located on that CEX-Bus segment, should not be performed unless such
interfaces already are in a non-operating state or their function is dispensable for
the controller.
Figure 36. BC820 Toggle Switch
Section 2 Installation Cables and Connectors
3BSE036351-600 A 113
Cables and Connectors
RCU Control Link: Modular Jack, RJ45, shielded twisted pair crossover cable with
all four pairs crossed: EIA/TIA-568 standard crossover T568A to T568B see
Table 10 below. Length: max 200m.
RCU Data Link: The optical interconnection is compatible with LC Duplex optical
connector interface conforming to ANSI TIA/EIA60-10 (FOCIS 10A). The type of
optical cable is 50/125µm OM3 fiber. Length: max 200m.
External 24V DC supply (L+, L-): Cable assembly for 2-pole terminal block.
Length: max 10m. Plugs included in package.
RCU-Link Cable TK857V0003: Cable between controller CPU and BC820.
Length: 0,3M. 2 pieces included in package.
All four pairs must be crossed.
Table 10. Crossover cable pinout (shown as T568A to T568B)
Connector A [pin] Color Connector B [pin] Color
1 White/Green 1 White/Orange
2 Green 2 Orange
3 White/Orange 3 White/Green
4 Blue 4 White/Brown
5 White/Blue 5 Brown
6 Orange 6 Green
7 White/Brown 7 Blue NXPP-06C NXPP06C 应DCS系统适配器主板 ABB
| | | |
