d 19200位/秒
•传输速度为1200比特/秒，高可达12000米（13100码）
连接器
将RS-232C通道连接至标有COM1和COM2的RJ45连接器
在TP853基板上。
表13.CI853 RS23-C接口——COM1和COM2连接器
引脚名称方向描述
1–9–见TP830中的COM3，91页的表6。
请注意，CI853单元没有单元冗余。
2节安装安装现场总线DP接口，CI854/CI854A/CI854B/TP854
3BSE036351-600 A 125
安装PROFIBUS DP接口，
CI854/CI854A/CI854B/TP854
CI854/CI854A/CI854B由处理器单元通过CEX总线供电
因此不需要额外的外部电源。
使用以下步骤安装CI854/CI854A/CI854B/TP854：
1.将装置安装到DIN导轨上，请参阅将AC 800M装置安装在DIN导轨上
在71页，并在单个中安装PM85x/PM86x/TP830处理器单元
84页的配置。
2.在PROFIBUS DP电缆上安装连接器。可切换的连接器
建议使用内置总线终端。将电缆屏蔽连接到金属上
通过CI854/CI854A/CI854B将屏幕接地的连接器外壳。连接
连接至端子PIN8（RxD/TxD-N）和数据电缆的数据电缆导线A
将导线B连接到端子PIN3（RxD/TxD-P）。如果数据传输电缆有数据
具有红色和绿色绝缘层的电线，则以下分配应为
用于：
数据电缆A线：绿色
数据电缆B线：红色
3.将两条线路的电缆屏蔽连接至功能接地，例如：
使用接地夹。
4.将PROFIBUS DP电缆连接到其中一个连接器PROFIBUS A或
底板上的PROFIBUS B。为了支持线路冗余，连接
另一个触点的二根PROFIBUS DP电缆。
5.如果CI854/CI854A/CI854B位于PROFIBUS DP电缆的末端，则切换
总线终端打开。否则，保持总线终端关闭。
以下适用于CI854A/CI854B：
6.如果CI854A/CI854B安装在冗余配置中，则连接
连接主模块和备用模块的PROFIBUS DP电缆。按照中的描述进行
图44126页。将主接口的终端打开
或位于线路末端的备份模块。
安装PROFIBUS DP接口，CI854/CI854A/CI854B/TP8542节安装
126 3BSE036351-600 A
PROFIBUS DP连接
PROFIBUS DP电缆通过9针内螺纹D型连接器连接
位于TP854上。
图44.冗余PROFIBUS DP的连接
2节安装安装现场总线DP接口，CI854/CI854A/CI854B/TP854
3BSE036351-600 A 127
PROFIBUS DP的安装
用于安装现场总线和推荐的认证现场总线设备，以及
组件，参见现场总线文件和附录C，推荐
组件。PROFIBUS DP必须采用屏蔽双绞线连接
电缆。
表14.CI854/CI854A/CI854B–PROFIBUS DP连接器
引脚名称描述
1屏蔽屏蔽/保护接地
2–未使用
3 RxD/TxD-P接收/发送数据P线（B线）
4 CNTR-P指示到中继器的方向（TTL）
5 DGND数字地面
6 VP+5 V，用于端接电阻器
7 – –
8 RxD/TxD-N接收/发送数据N线（A线）
9 DGND数字地面
请注意，CI854单元没有单元冗余。只为
CI854A/CI854B。主总线300接口，CI855/TP853
CI855由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
底板TP853提供两个以太网端口，用于连接冗余
主总线300的以太网网络。
使用以下步骤安装CI855/TP853：
1.将装置安装在DIN导轨上，参见将AC 800M装置安装到DIN导轨上
在71页，并在单个中安装PM85x/PM86x/TP830处理器单元
84页的配置。
2.将以太网双绞线连接至底板上的触点。
3.将以太网电缆的另一端连接到以太网交换机。
以太网双绞线连接
以太网双绞线通过位于的10BaseT RJ45连接器连接
TP853.有关连接器的说明，请参见90页的表5。
如果需要AUI接口，则需要10BaseT到AUI的转换器。
通信单元CI855不能向收发器供电，因此
必须使用单独的电源。
请注意，CI855单元没有单元冗余。
2节安装安装S100 I/O接口，CI856/TP856
3BSE036351-600 A 129
安装S100 I/O接口，CI856/TP856
CI856由处理器单元通过CEX总线供电，需要：
因此不需要额外的外部电源。
使用以下步骤安装CI856/TP856：
1.将装置安装在DIN导轨上，参见将AC 800M装置安装到DIN导轨上
在71页，并在单个中安装PM85x/PM86x/TP830处理器单元
84页的配置。
2.将S100输入/输出电缆TK575/TK580连接至基板上的触点。A.
