the IP address of the CN1 port on the backup CPU. Use default settings
(0.0.2.0 is added to the address of the primary CPU), unless your network
administrator requires otherwise. See IPConfig online help.
4. Start your 800xA Workplace.
5. Create a representation of the controller in the Project Explorer hardware tree.
Make sure the PM858/PM861/PM862/PM864/PM865/PM866/PM867/PM891
processor unit is defined as redundant. See Control Builder online help.
6. In Project Explorer, set the IP address of the controller to the IP address of the
primary CPU. See Control Builder online help.
7. Switch on the secondary CPU. Check that you have communication with the
controller.
I/O Systems
There are several methods of connecting I/O systems to the AC 800M Controller:
• S100 I/O via CI856.
• S800 I/O units via the ModuleBus. Support for hot configuration during run,
redundancy on all levels, HART routing, and Sequence-of-Events (SOE).
• S800 I/O units via CI854/CI854A/CI854B and CI840/CI840A, PROFIBUS
DP. Support for HART routing, redundancy on all levels, and hot configuration
during run.
• S800 I/O units via CI854/CI854A/CI854B and CI801, PROFIBUS DP. Support
for HART routing, and hot configuration during run.
• S900 I/O units can be connected to PROFIBUS DP.
If network redundancy is used, you also have to set the IP address of the CN2
port of the backup processor using IPConfig. See IPConfig online help.
There is no need to set IP address(es) for the backup CPU in Control Builder.
The IP address of the backup CPU, CN1 and CN2 ports will only be used for
internal communication between the primary and backup CPUs. When the
backup CPU takes over, it also takes over the primary IP address that is defined
in Control Builder. Other units on the control network will never notice the
switchover.
Section 3 Configuration I/O Systems
3BSE036351-600 A 167
• ABB Drives can be connected to the ModuleBus, via CI801 and also via
Modulebus on the PM8xx. Some Drives equipment can be connected directly
to PROFIBUS or PROFINET IO. Please refer to Drives-specific
documentation for more information.
• Genius remote I/O (TRIO) via the CI862 Interface
• Satt I/O on ControlNet (19” Satt rack I/O, S200 I/O and S200L I/O) via the
CI865
• PROFINET IO via CI871
For more information on supported I/O systems and units, see I/O documentation.
ModuleBus
The ModuleBus in the AC 800M controller, except PM891, consists of one
electrical and one optical unit. The PM891 consists of optical ModuleBus only.
The following are the details of the ModuleBus:
• Electrical ModuleBus, (see Figure 59 on page 168) – 1 cluster (group), with a
maximum of 12 S800 I/O units connected.
• Optical ModuleBus (see Figure 59 on page 168) – 7 clusters (groups), with
maximum 7 x 12 = 84 S800 I/O units connected.
Note that the electrical ModuleBus can only be used for connection of S800 I/O
when AC 800M is running in single CPU configuration.
PM851/PM851A is restricted to one optical ModuleBus cluster.
Use of redundancy will reduce the maximum number of S800 channels. Each
cluster may contain up to 12 single S800 I/O units or up to 6 redundant S800 I/O
units.
I/O Systems Section 3 Configuration
168 3BSE036351-600 A
This provides a total of eight clusters (groups), with a maximum 8 x 12 = 96 S800
I/O units connected to an AC 800M Controller with single CPU configuration.
Figure 59. Electrical and Optical ModuleBus Configuration
Maximum of 7
clusters (groups)
Maximum of 12 x I/O units
PM8xx
TB840
TB840
TB840 Optical
Local
ModuleBus
Central/Remote
Optical
ModuleBus
Electrical
ModuleBus
(Maximum of 1
cluster for PM851)
Section 3 Configuration I/O Systems
3BSE036351-600 A 169
In redundant CPU configuration, S800 I/O is connected through the optical
ModuleBus. Each CPU is connected to one TB840 on each cluster (see Figure 60 on
page 169).
Figure 60. Optical ModuleBus connection in redundant CPU configuration
Maximum of 7
clusters (groups)
Maximum of 12 x I/O units
2 x TB840
2 x TB840
2 x TB840
Optical
Local
ModuleBuses
Central/Remote
Redundant CPUs
Electrical ModuleBus cannot be used
I/O Systems Section 3 Configuration
170 3BSE036351-600 A
PROFIBUS DP
A PROFIBUS DP segment, capable of providing up to 32 nodes, can be directly
connected to a PROFIBUS DP Interface unit type CI854A/CI854B/TP854. This
segment can be further extended using repeater units.
PROFIBUS PA can be connected to PROFIBUS DP via the PROFIBUS linking
device LD 800P, see Appendix C, Recommended Components. For further details
refer to PROFIBUS documentation, available at the PROFIBUS Internet site.
It is possible to connect the following I/O systems to the PROFIBUS DP:
• S800 I/O and/or S800L I/O via FCI – refer to S800 I/O documentation.
• S900 I/O via FCI CI920 - refer to S900 I/O documentation.
• S200 I/O and/or S200L I/O 140NOM21100 MB+ 网络适配器PLC模块 1MB Schneider
| | | |
