手动推动
按钮
发起
1.如果INIT保持小于2.5，则冷重启
秒。
2.如果INIT保持时间超过
3秒。
如果在主CPU上按下INIT，则
冗余配置a切换到
将启动备份CPU。
表21.PM8xx/TP830和PM891–连接器
标记功能
L+
L——
沙特阿拉伯
某人
外部电源连接
+24伏直流电源
0V
冗余电源监控输入
冗余电源监控输入
SH
B+
B——
外部电池连接
屏蔽（螺纹连接器）
蓄电池正极（螺纹接头）
蓄电池负极（螺纹接头）
德克萨斯州
处方药
模块总线连接
数据传输端口（光）
数据接收端口（光学）
注：可使用双工或单工光缆。
模块总线（1）提供了I/O单元能力的扩展。
4节运行启动
3BSE036351-600 A 191
启动
有关以下方面的信息，请参阅相关文件：
•固件下载
•控制器IP地址
•下载应用程序
•更新固件
冗余配置启动（CEX总线考虑事项）
支持使用CEX总线和CEX模块的冗余配置
对于处理器模块PM858、PM861、PM862、PM864、PM865、PM866，
PM867和PM891。
启动时，有关CEX总线和CEX模块的一些事项必须：
启动冗余AC 800M系统时应考虑：
•不使用BC810装置：
CEX-BUS提供车载通信端口的扩展。
适用于PM858/PM861/PM862/PM864/PM865/PM866/PM867
RCU链路连接器提供主设备之间的信息和数据传输
以及冗余配置的备份CPU。
适用于PM891
RCU数据链路
连接器
提供保留备份所需的数据传输
与主CPU同步的CPU。
RCU控制链路
连接器
提供角色选择和CPU标识分配。
（1） 电气模块总线对PM891无效。
表21.PM8xx/TP830和PM891–连接器（续）
标记功能
启动模式4节运行
192 3BSE036351-600 A
–如果有基板，则必须至少插入一个CEX模块
在其他位置插入模块。
–在CEX总线上重建硬件后，即在移除后
或添加多个基板（是否配备CEX模块）
上层CPU（连接到RCU链路电缆部分的CPU
标记为“上”）必须一次作为主CPU启动。
启动模式
热启动
启动应用程序控制任务。变量值初始化，除非
标记为保留或冷保留。
要启动热重启，请断开电源几秒钟。
电源故障后，热重启功能将自动启动
在电源恢复时。
冷重启
应用程序重新启动。变量值初始化，除非标记为“冷”
保持
要启动冷重启，必须通过短按重新启动控制器
初始化按钮（小于2.5秒）。
冗余配置中的冷重启
要重新启动以冗余配置运行的CPU：
1.执行备份CPU的控制器重置（见下文）。该系统将继续运行
进入单CPU状态。
2.等待几秒钟，然后按INIT重新启动主CPU
按下按钮不到2.5秒。
电源故障后，而不是热重启应用程序SIL3
使用保存在控制器中的冷保留标记值重新启动应用程序
以用户设置的周期时间周期性地进行。
4节操作自动切换至备用CPU
3BSE036351-600 A 193
3.系统将再次升级到同步CPU状态。
控制器复位
系统停止。应用程序和变量被擦除。
要启动控制器重置，请按住控制器初始化按钮（更多
超过三秒），直到运行LED开始闪烁。控制器重置必须：
如果系统处于未定义位置，因此不可用，则执行
用户。
冗余配置中的控制器重置
按照以下步骤执行冗余配置中的控制器重置：
1.执行备份CPU的控制器重置。系统将采用单CPU
状态
2.等待几秒钟，然后在主CPU上执行控制器重置。
自动切换到备份CPU
在冗余配置中，从主CPU到
备份CPU在以下情况下发生，前提是它们处于同步状态
状态（双LED点亮）：
•主CPU内存错误。
•主CPU中的其他硬件错误，导致CPU崩溃。
•控制网络上的严重通信错误，即两种情况都丢失
主CPU中的网络端口。
•模块总线上的严重通信错误（如果模块总线是
HW配置），即主CPU中的群集丢失。
请注意，ModuleBus上存在严重通信错误的备份CPU
将被拒绝（如果ModuleBus是硬件配置的一部分），并且
只要出现错误，就永远不会达到同步状态 通用电气 745-W2-P5-G5-HI-R-E 安装在综合保护继电器 GE
 通用电气 745-W2-P5-G5-HI-R-E 安装在综合保护继电器 GE
通用电气 745-W2-P5-G5-HI-R-E 安装在综合保护继电器 GE
Manual Push
button
Initiates
1. Cold Restart if INIT is held less than 2.5
seconds.
2. Controller Reset if INIT is held more than
3 seconds.
If INIT is pushed on the Primary CPU in
redundant configuration a switchover to the
backup CPU will be initiated.
Table 21. PM8xx/TP830 and PM891 – Connectors
Marking Function
L+
L–
SA
SB
External Power Supply Connection
+24 V DC supply
0 V
Redundant Power Supply monitoring input
Redundant Power Supply monitoring input
SH
B+
B–
External Battery Connection
Shield (Screw Connector)
Battery Positive (Screw Connector)
Battery Negative (Screw Connector)
Tx
Rx
ModuleBus Connection
Data Transmission Port (Optical)
Data Reception Port (Optical)
Note – Duplex or Simplex optical cables may be used.
MODULEBUS(1) Provides expansion of I/O unit capability.
Section 4 Operation Start-up
3BSE036351-600 A 191
Start-up
Refer to relevant document for information on:
• Firmware download
• Controller IP address
• Downloading application
• Updating firmware
Start-up in Redundant Configuration (CEX Bus Considerations)
The redundant configuration using CEX bus and CEX modules is supported along
with the processor modules PM858, PM861, PM862, PM864, PM865, PM866,
PM867 and PM891.
At start-up, some things regarding the CEX bus and CEX modules have to be
considered when starting up a redundant AC 800M system:
• Without using BC810 units:
CEX-BUS Provides extension of on-board communication ports.
Valid for PM858/PM861/PM862/PM864/PM865/PM866/PM867
RCU Link Connector Provides information and data transfer between Primary
and Backup CPU in redundant configuration.
Valid for PM891
RCU Data Link
Connector
Provides transfer of data required to keep the backup
CPU synchronized with the primary CPU.
RCU Control Link
Connector
Provides role selection and CPU identity assignment.
(1) Electrical ModuleBus not valid for PM891.
Table 21. PM8xx/TP830 and PM891 – Connectors (Continued)
Marking Function
Start Modes Section 4 Operation
192 3BSE036351-600 A
– At least one CEX module must be inserted, if there are base plates without
inserted modules in other positions.
– After having rebuilt the hardware on the CEX bus, that is, after removing
or adding a number of base plates (equipped with CEX modules or not)
the upper CPU (the CPU connected to the part of the RCU Link cable that
is marked “UPPER”) must be started as the primary CPU the first time.
Start Modes
Warm Start
Application-controlling tasks are initiated. Variable values are initialized unless
marked Retain or Cold retain.
To initiate a warm restart, disconnect the power supply for a few seconds.
Following a power failure, the warm restart function will be automatically initiated
on power restoration.
Cold Restart
The application program restarts. Variable values are initialized unless marked Cold
retain.
To initiate a cold restart, the Controller must be restarted by briefly pressing
the INIT push button (less than 2.5 seconds).
Cold Restart in Redundant Configuration
To restart CPUs running in redundant configuration:
1. Perform a Controller Reset of the backup CPU (see below). The system will go
into single CPU state.
2. Wait a few seconds and then restart the Primary CPU by pressing the INIT
push button less than 2.5 seconds.
After a power fail, instead of doing a warm restart of the application SIL3
applications are restarted using cold retain marked values saved in the controller
periodically with a cycle time set by the user.
Section 4 Operation Automatic Switch-Over to Backup CPU
3BSE036351-600 A 193
3. The system will be upgraded to synchronized CPU state once again.
Controller Reset
The system stops. The application program and variables are erased.
To initiate Controller Reset, press and hold the Controller INIT push button (more
than three seconds) until the Run LED begins to flash. A Controller Reset must be
performed if the system is in an undefined position and consequently unavailable to
the user.
Controller Reset in Redundant Configuration
Follow the steps below to perform a Controller Reset in redundant configuration:
1. Perform a Controller Reset of the backup CPU. The system will go single CPU
state.
2. Wait a few seconds and then perform a Controller Reset on the Primary CPU.
Automatic Switch-Over to Backup CPU
In a redundant configuration an automatic switch-over from the Primary CPU to the
Backup CPU occurs in the following situations, provided they are in synchronized
state (DUAL LED is lit):
• Memory error in the Primary CPU.
• Other HW-error in the Primary CPU, which causes CPU crash.
• Severe communication errors on the Control network, that is, loss of both
network ports in the Primary CPU.
• Severe communication errors on the ModuleBus (if ModuleBus is part of the
HW configuration) that is, loss of clusters in the Primary CPU.
Note that a Backup CPU with severe communication errors on the ModuleBus
will be rejected (if ModuleBus is part of the HW configuration) and
synchronized state will never be reached as long as error remains. | 通用电气 745-W2-P5-G5-HI-R-E 安装在综合保护继电器 GE | | | | |
