500L-GOD93 DCS系统电力电路综合保护接触器 A-B
CI854/CI854A/CI854B现场总线DP单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI855主总线300的以太网接口单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI856 S100输入/输出接口单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
C（操作失败）红色LED必须关闭正常
CI857 INSUM装置
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI858驱动总线单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI860基金会现场总线高速以太网单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI862三路输入/输出接口单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
表22.AC 800M控制器-验证系统运行是否令人满意
LED指示灯状态
AC 800M
控制器
地位
单CPU4节操作验证
196 3BSE036351-600 A
CI865 Satt I/O接口单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI867 Modbus TCP接口单元
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI868
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI869
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI871
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI872
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
CI873
F（故障）红色LED必须熄灭，正常
R（un）绿色LED必须亮起（稳定）OK
表22.AC 800M控制器-验证系统运行是否令人满意
LED指示灯状态
AC 800M
控制器
地位
四节冗余CPU的运行验证
3BSE036351-600 A 197
冗余CPU的验证
在冗余配置中，检查以下LED指示灯是否亮起
PM858/PM861/PM862/PM864/PM865/PM866/PM867/PM891，
SM810/SM811/SM812（见197页表23）。
通过以下方式启动手动切换：
•重置主CPU
•关闭主CPU电源
检查两个CPU上的黄色双LED是否随后亮起，以及
PRIM LED在以前的备用CPU上亮起，现在充当主CPU。
其他单位见194页表22 500L-GOD93 DCS系统电力电路综合保护接触器 A-B
 500L-GOD93 DCS系统电力电路综合保护接触器 A-B
CI854/CI854A/CI854B PROFIBUS DP Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI855 Ethernet Interface Unit for MasterBus 300
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI856 S100 I/O Interface Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
C(omm. fail) Red LED must be OFF OK
CI857 INSUM Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI858 DriveBus Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI860 FOUNDATION Fieldbus High Speed Ethernet Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI862 TRIO I/O Interface Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
Table 22. AC 800M Controller – Verification of Satisfactory System Operation
LED Indicator Status
AC 800M
Controller
Status
Verification of Single CPU Section 4 Operation
196 3BSE036351-600 A
CI865 Satt I/O Interface Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI867 Modbus TCP Interface Unit
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI868
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI869
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI871
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI872
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
CI873
F(ault) Red LED must be OFF OK
R(un) Green LED must be ON (steady) OK
Table 22. AC 800M Controller – Verification of Satisfactory System Operation
LED Indicator Status
AC 800M
Controller
Status
Section 4 Operation Verification of Redundant CPU
3BSE036351-600 A 197
Verification of Redundant CPU
Check, in redundant configuration, the following LED indicators on
PM858/PM861/PM862/PM864/PM865/PM866/PM867/PM891 and, if used,
SM810/SM811/SM812 (see Table 23 on page 197).
A manual switch-over is initiated by:
• Resetting the Primary CPU
• Powering off the Primary CPU
Check that the yellow DUAL LED subsequently lights up on both CPUs, and that
the PRIM LED lights up on the former Backup CPU now acting as Primary CPU.
For other units see Table 22 on page 194 | 500L-GOD93 DCS系统电力电路综合保护接触器 A-B | | | |
