所有电缆和连接器是否损坏，以及
连接松动或不良。必要时进行修理。
R（un）LED闪烁检查相关装置是否正在发送数据。
检查CI857板是否处于
正在重新启动或配置。如果是，请留出时间
这是后定稿。
如果条件持续存在：
•停止应用程序并启动
重新启动。
•更换CI857板。
Tx1 LED亮起（不闪烁）表示装置未传输数据。
•检查CB是否有故障信息。
Rx1 LED亮起（不闪烁）表示装置未接收数据。
•检查所有电缆和连接。
CI857支持热插拔。
驱动总线接口-CI858第5节维护
226 3BSE036351-600 A
驱动总线接口-CI858
表36.驱动总线CI858——故障查找
故障、可能原因和纠正措施
R（un）和F（ault）指示灯均不亮
正在
CI858板正在开发过程中
重新启动或配置。留出时间
定稿
如果条件持续存在，并且没有其他装置指示灯点亮
CEX总线点亮：
•检查有效的硬件配置，包括：
将CI858下载到控制器。
•检查内部的CEX总线保险丝
处理器单元。
•从
处理器单元。
•更换CI858装置。
单元错误或初始化时，F（ault）指示灯亮起。
检查所有电缆和接头是否损坏，以及
连接松动或不良。
•必要时进行维修。
Dbus；Rx1 LED亮起（不亮
闪光）
该装置未接收数据。
•检查所有电缆和连接。
•更换CI858装置。
Dbus；Rx1 LED熄灭，无信号发送至装置或装置错误。
•检查所有电缆和连接。
•更换CI858装置。
Dbus；Tx1 LED亮起（不亮
闪光）
该单元不传输数据。
•检查CB是否有故障信息。
•如果CB中没有故障信息
更换CI858装置。
第5节维护驱动总线接口-CI858
3BSE036351-600 A 227
Dbus；Tx1指示灯熄灭、装置未正确配置或装置错误。
•检查CB是否有故障信息。
•如果没有故障信息，则更换
CI858单元。
输入/输出；Rx1 LED亮起（不亮
闪光）
该装置未接收数据。
•检查所有电缆和连接。
•如果没有故障信息，则更换
CI858单元。
输入/输出；Rx1 LED熄灭，无信号发送至装置或装置错误。
•检查所有电缆和连接。
•更换CI858装置。
输入/输出；Tx1 LED亮起（不亮
闪光）
该单元不传输数据。
•检查CB是否有故障信息。
•如果CB中没有故障信息
更换CI858装置。
输入/输出；Tx1指示灯熄灭、装置未正确配置或装置错误。
•检查CB是否有故障信息。
•如果没有故障信息，则更换
CI858单元。
CI858支持热插拔。
表36.驱动总线CI858——故障查找（续）
故障、可能原因和纠正措施
基金会现场总线高速以太网-CI860第5节维护
228 3BSE036351-600 A
基金会现场总线高速以太网-CI860
表37.基金会现场总线高速以太网CI860——故障查找
故障、可能原因和纠正措施
R（un）和F（ault）指示灯均不亮
正在
CI860板正在开发中
重新启动或配置。留出时间
后确定。
如果条件持续存在，并且没有其他装置指示灯点亮
CEX总线点亮：
•检查有效的硬件配置，包括：
将CI860下载到控制器。
•检查日志文件
•检查CPU单元内的CEX总线保险丝。
•从CPU启动复位信号（INIT）
单元
•更换CI860装置。
F（故障）指示灯亮起。检查所有电缆和接头是否损坏，以及
连接松动或不良。
必要时进行修理。
R（un）LED闪烁检查相关装置是否正在发送数据。
检查CI860板是否处于
正在重新启动或配置。如果是，请留出时间
这是后定稿。
如果条件持续存在：
•停止应用程序并启动
重新启动。
•检查日志文件
•更换CI860板。
如果RxTx LED闪烁，则100Mbit/s开启：
建立了100Mbit/s的有效连接。
第5节维护基金会现场总线高速以太网-CI860
3BSE036351-600 A 229
如果RxTx LED闪烁，则100Mbit/s关闭：
建立10 MBit/s的有效连接。
RxTx LED位于与相应以太网设备的链路上
已建立。没有以太网包
发送/接收。
RxTx指示灯闪烁。与相应以太网设备的链接为
已建立。发送/接收以太网包
RxTx指示灯关闭，与相应以太网单元的链路未关闭
确立
•检查日志文件
•检查连接至的以太网电缆
对应的以太网设备。
•检查相应的以太网设备。
•检查CI8 AG 018078.07 B6 AVIV700 模拟控制卡 SCHENCK
AG 018078.07 B6 AVIV700 模拟控制卡 SCHENCK
all cables and connectors for damage and
loose or poor connections. Repair as necessary.
R(un) LED is flashing Check that the relevant units are sending data.
Check if the CI857 board is in the process of
being restarted or configured. If so, allow time for
this to finalize.
If the condition persists:
• Halt the application program and initiate a
restart.
• Replace the CI857 board.
Tx1 LED is ON (not flashing) The unit is not transmitting data.
• Check the CB for a failure message.
Rx1 LED is ON (not flashing) The unit is not receiving data.
• Check all cables and connections.
CI857 supports hot swap.
DriveBus Interface - CI858 Section 5 Maintenance
226 3BSE036351-600 A
DriveBus Interface - CI858
Table 36. DriveBus CI858 – Fault-Finding
Fault Possible Cause and Corrective Action
Neither R(un) nor F(ault) LEDs
are ON
The CI858 board is in the process of being
restarted or configured. Allow time for this to
finalize
If the condition persists, and no other unit LED on
the CEX-Bus is lit:
• Check that a valid HW configuration including
the CI858 is downloaded to the controller.
• Check the CEX-Bus fuse inside the
processor unit.
• Initiate a reset signal (INIT) from the
processor unit.
• Replace the CI858 unit.
F(ault) LED is ON Unit error or initializing.
Check all cables and connectors for damage and
loose or poor connections.
• Repair as necessary.
Dbus;Rx1 LED is ON (not
flashing)
The unit is not receiving data.
• Check all cables and connections.
• Replace the CI858 unit.
Dbus;Rx1 LED is OFF No signals are sent to the unit or unit error.
• Check all cables and connections.
• Replace the CI858 unit.
Dbus;Tx1 LED is ON (not
flashing)
The unit is not transmitting data.
• Check the CB for a failure message.
• If there is no failure message in the CB
replace the CI858 unit.
Section 5 Maintenance DriveBus Interface - CI858
3BSE036351-600 A 227
Dbus;Tx1 LED is OFF The unit is not properly configured or unit error.
• Check the CB for a failure message.
• If there is no failure message replace the
CI858 unit.
I/O;Rx1 LED is ON (not
flashing)
The unit is not receiving data.
• Check all cables and connections.
• If there is no failure message replace the
CI858 unit.
I/O;Rx1 LED is OFF No signals are sent to the unit or unit error.
• Check all cables and connections.
• Replace the CI858 unit.
I/O;Tx1 LED is ON (not
flashing)
The unit is not transmitting data.
• Check the CB for a failure message.
• If there is no failure message in the CB
replace the CI858 unit.
I/O;Tx1 LED is OFF The unit is not properly configured or unit error.
• Check the CB for a failure message.
• If there is no failure message replace the
CI858 unit.
CI858 supports hot swap.
Table 36. DriveBus CI858 – Fault-Finding (Continued)
Fault Possible Cause and Corrective Action
FOUNDATION Fieldbus High Speed Ethernet - CI860 Section 5 Maintenance
228 3BSE036351-600 A
FOUNDATION Fieldbus High Speed Ethernet - CI860
Table 37. FOUNDATION Fieldbus High Speed Ethernet CI860 – Fault-Finding
Fault Possible Cause and Corrective Action
Neither R(un) nor F(ault) LEDs
are ON
The CI860 board is in the process of being
restarted or configured. Allow time for this to
finalize.
If the condition persists, and no other unit LED on
the CEX-Bus is lit:
• Check that a valid HW configuration including
the CI860 is downloaded to the controller.
• Check the Log File
• Check the CEX-Bus fuse inside the CPU unit.
• Initiate a reset signal (INIT) from the CPU
unit.
• Replace the CI860 unit.
F(ault) LED is ON Check all cables and connectors for damage and
loose or poor connections.
Repair as necessary.
R(un) LED is flashing Check that the relevant units are sending data.
Check if the CI860 board is in the process of
being restarted or configured. If so, allow time for
this to finalize.
If the condition persists:
• Stop the application program and initiate a
restart.
• Check the Log File
• Replace the CI860 board.
100Mbit/s is ON If RxTx LED is flashing:
A valid connection with100 MBit/s is established.
Section 5 Maintenance FOUNDATION Fieldbus High Speed Ethernet - CI860
3BSE036351-600 A 229
100Mbit/s is OFF If RxTx LED is flashing:
A valid connection with10 MBit/s is established.
RxTx LED is ON A link to the corresponding ethernet device is
established. No Ethernet packages are
sent/received.
RxTx LED is flashing A link to the corresponding ethernet device is
established. Ethernet packages are sent/received
RxTx LED is OFF A link with the corresponding ethernet unit is not
established
• Check the Log File
• Check the ethernet cable to the
corresponding ethernet device.
• Check the corresponding ethernet device.
