指示：可能的原因和纠正措施
R（联合国）和
F（故障）指示灯亮起
CI862正在重新启动，或
配置。留出时间完成这项工作。
如果条件持续存在，并且CEXbus上的所有其他单元都有不发光的LED：
•检查有效的硬件配置，包括
CI862被下载到控制器。
•检查PM8xx内的CEX总线保险丝
处理器单元。
•从PM8xx启动复位信号（INIT）
处理器单元。
•更换CI862。
F（ault）指示灯亮起。检查CI862是否正在运行
重新启动。留出时间完成这项工作。
检查是否没有从报告的配置故障
CBM中的CI862。如果状态保持不变，则启动复位信号
（初始化）来自PM8xx处理器单元。如果状态仍然
复位后保持，更换CI862。
通信错误指示灯为
上
µGenie从站的现场总线通信错误
单元
PRIM LED熄灭，CI862正在重新启动，或
配置。留出时间完成这项工作。
检查是否没有从报告的配置故障
CBM中的CI862。
双LED熄灭，亮起
两个CI862
CI862正在重新启动，或
配置。留出时间完成这项工作。
检查此模块的冗余是否设置在
CBM和配置已下载。
CI862支持热插拔。
第5节维护Satt I/O接口——CI865
3BSE036351-600 A 231
Satt I/O接口——CI865
表39.Satt输入/输出CI865——故障查找
故障、可能原因和纠正措施
行动
CI865装置上的R（un）和F（ault）指示灯均不亮，但正在运行
配置。留出时间完成这项工作。
如果条件持续存在，并且没有其他
CEX总线上的单元LED点亮：
•检查有效的硬件配置
包括CI865
到控制器。
•检查内部的CEX总线保险丝
PM8xx处理器单元
•从以下位置启动复位信号（INIT）：
PM8xx处理器单元
•更换CI865装置
F（ault）指示灯亮起，CI865装置正在运行
重新启动。留出时间完成这项工作。
如果情况仍然存在，请更换装置。
COM A/COM B LED处于关闭、关闭电源或重置模式
COM A/COM B LED呈绿色，通道正常
COM A/COM B指示灯呈绿色闪烁。临时错误或需要初始设置
COM A/COM B LED为实心红色模块损坏，必须更换
COM A/COM B指示灯闪烁红色，通道电缆损坏
COM A/COM B LED为铁路红色。道路配置不正确
网络
COM A/COM B指示灯闪烁红色/绿色。网络存在数据流问题
COM A/COM B LED是铁路红色/绿色自检
CI865支持热插拔。
Modbus TCP接口——CI867第5节维护
232 3BSE036351-600 A
Modbus TCP接口——CI867
表40.Modbus TCP接口CI867-故障查找
故障、可能原因和纠正措施
R（un）和F（ault）LED均不
上
CI867单元正在开发过程中
配置。留出时间完成这项工作。如果
该情况持续存在，并且没有其他单元指示灯
CEX总线上的灯亮：
•检查有效的硬件配置
包括CI867下载到
控制器。
•检查内部的CEX总线保险丝
PM8xx处理器单元。
•从
PM8xx处理器单元。
•更换CI867装置。
F（ault）指示灯亮起，CI867装置正在运行
重新启动。留出时间完成这项工作。
如果情况仍然存在，请更换装置。
RxTx1/RxTx2指示灯熄灭，没有接收或发送活动
各自的以太网信道。
RxTx1/RxTx2 LED闪烁，接收或发送活动
以太网信道正常。
PRIM在非冗余模式下关闭：
•该模块不是由
应用
在冗余模式下：
•该模块不是由
应用程序或此模块充当
备份接口。
第5节维护Modbus TCP接口——CI867
3BSE036351-600 A 233
PRIM在非冗余模式下打开：
•本模块由
应用
在冗余模式下：
•本模块由
应用程序和此模块充当
主要接口。
双在非冗余模式下关闭：
•在非冗余状态下始终关闭
模式
在冗余模式下：
•该模块未同步，或者
该冗余对中的其他模块为：
这还没有开始。
在非冗余模式下，DUAL开启：
•不适用
在冗余模式下：
•该模块未同步，或者
该冗余对中的其他模块为：
这还没有开始。
CI867支持热插拔。
表40.Modbus TCP接口CI867-故障查找
故障、可能原因和纠正措施
IEC 61850接口–CI868第5节维护
234 3BSE036351-600 A
IEC 61850接口——CI868
表41.IEC 61850接口CI868-故障查找
故障、可能原因和纠正措施
R（un）和F（ault）LED均不
上
CI868单元正在开发过程中
配置。留出时间完成这项工作。如果
该情况持续存在，并且没有其他单元指示灯
在CEX总线上：
•检查有效的硬件配置
包括CI868下载到
控制器。
•检查内部的CEX总线保险丝 Adept 05215-110 移动手持示教器 T2 Pendant 10m
 Adept 05215-110 移动手持示教器 T2 Pendant 10m
ndication Possible Cause and Corrective Action
Neither R(un) nor
F(ault) LED’s are ON
The CI862 is in the process of being restarted or
configured. Allow time for this to finalize.
If the condition persists, and all other units on the CEXbus have non-illuminated LEDs:
• Check that a valid HW configuration including the
CI862 is downloaded to the controller.
• Check the CEX-bus fuse inside the PM8xx
processor unit.
• Initiate a reset signal (INIT) from the PM8xx
processor unit.
• Replace the CI862.
F(ault) LED is ON Check that the CI862 is in the process of being
restarted. Allow time for this to finalize.
Check that there is no configuration fault reported from
CI862 in CBM.If the status remains, initiate a reset signal
(INIT) from the PM8xx processor unit. If the status still
remains after the reset replace the CI862.
COMM ERROR LED is
ON
Field Bus Communication Error from the µGenie slave
module.
PRIM LED is OFF The CI862 is in the process of being restarted or
configured. Allow time for this to finalize.
Check that there is no configuration fault reported from
CI862 in CBM.
DUAL LED is OFF on
both CI862’s
The CI862 is in the process of being restarted or
configured. Allow time for this to finalize.
Check that the redundancy for this module is set within
CBM and the configuration is downloaded.
CI862 supports hot swap.
Section 5 Maintenance Satt I/O Interface – CI865
3BSE036351-600 A 231
Satt I/O Interface – CI865
Table 39. Satt I/O CI865 – Fault Finding
Fault Possible Cause and Corrective
Action
Neither R(un) nor F(ault) LED’s are ON The CI865 unit is in the process of being
configured. Allow time for this to finalize.
If the condition persists, and no other
unit LED on the CEX-Bus is lit:
• Check that a valid HW configuration
including the CI865 is downloaded
to the controller.
• Check the CEX-Bus fuse inside the
PM8xx processor unit
• Initiate a reset signal (INIT) from
the PM8xx processor unit
• Replace the CI865 unit
F(ault) LED is ON The CI865 unit is in the process of being
restarted. Allow time for this to finalize.
Replace unit if the condition persists.
COM A/COM B LED is OFF Power OFF or Reset Mode
COM A/COM B LED is solid green Channel OK
COM A/COM B LED is flashing green Temporary error or need initial setup
COM A/COM B LED is solid red Module is broken, has to be replaced
COM A/COM B LED is flashing red Bad channel cable
COM A/COM B LED is railroad red The road is not configured right for the
network
COM A/COM B LED is flashing red/green Network has data flow problem
COM A/COM B LED is railroad red/green Self test
CI865 supports hot swap.
Modbus TCP Interface – CI867 Section 5 Maintenance
232 3BSE036351-600 A
Modbus TCP Interface – CI867
Table 40. Modbus TCP Interface CI867 - Fault Finding
Fault Possible Cause and Corrective Action
Neither R(un) nor F(ault) LED's are
ON
The CI867 unit is in the process of being
configured. Allow time for this to finalize. If
the condition persist, and no other unit LED
on the CEX-Bus is lit:
• Check that a valid HW configuration
including the CI867 is downloaded to
the controller.
• Check the CEX-Bus fuse inside the
PM8xx processor unit.
• Initiate a reset signal (INIT) from the
PM8xx processor unit.
• Replace the CI867 unit.
F(ault) LED is ON The CI867 unit is in the process of being
restarted. Allow time for this to finalize.
Replace unit if the condition persists.
RxTx1/RxTx2 LED is OFF No Receive or transmit activity for
respective Ethernet channels.
RxTx1/RxTx2 LED is flashing Receive or transmit activity for respective
Ethernet channels is normal.
PRIM is OFF In non-redundant mode:
• This module is not started by the
application.
In redundant mode:
• This module is not started by the
application or this module act as
backup interface.
Section 5 Maintenance Modbus TCP Interface – CI867
3BSE036351-600 A 233
PRIM is ON In non-redundant mode:
• This module is started by the
application.
In redundant mode:
• This module is started by the
application and this module act as the
primary interface.
DUAL is OFF In non-redundant mode:
• This is always OFF in non-redundant
mode.
In redundant mode:
• This module is not synchronized or the
other module in this redundant pair is
not started.
DUAL is ON In non-redundant mode:
• N/A
In redundant mode:
• This module is not synchronized or the
other module in this redundant pair is
not started.
CI867 supports hot swap.
Table 40. Modbus TCP Interface CI867 - Fault Finding
Fault Possible Cause and Corrective Action
IEC 61850 Interface – CI868 Section 5 Maintenance
234 3BSE036351-600 A
IEC 61850 Interface – CI868
Table 41. IEC 61850 Interface CI868 - Fault Finding
Fault Possible Cause and Corrective Action
Neither R(un) nor F(ault) LED's are
ON
The CI868 unit is in the process of being
configured. Allow time for this to finalize. If
the condition persist, and no other unit LED
on the CEX-Bus is ON:
• Check that a valid HW configuration
including the CI868 is downloaded to
the controller.
• Check the CEX-Bus fuse inside the
PM8xx processor unit.
• Initiate a reset signal (INIT) from the
PM8xx processor unit.
• Replace the CI868 unit.
• None application is downloaded.
F(ault) LED is ON The CI868 unit is in the process of being
restarted. Allow time for this to finalize.
Replace unit if the condition persists.
RxTx1/RxTx2(1) LED is OFF
(1) LED will always be switched off due to disabling of channel CH2
No Receive or transmit activity for
respective Ethernet channels.
RxTx1/RxTx2(1) LED is flashing Receive or transmit activity for respective
Ethernet channels is normal.
Since CI868 does not support redundancy, the PRIM and DUAL LED is not used.
However, the PRIM LED is ON in a single configuration of CI868.
CI868 supports hot swap.
Section 5 Maintenance AF 100 Interface - CI869
3BSE036351-600 A 235
AF 100 Interface - CI869
The Mast LED in the CI869 module is not used. Table 42 lists the other indications.
Table 42. AF 100 Interface, CI869 - Indications and Fault Finding
Indication Possible Cause and Corrective Action (for faults)
Both R(un) and F(ault)
LED's are OFF
Possible Cause 1: The CI869 module is connected
to the controller, but the configuration is not
downloaded to the controller for that position.
Corrective Action 1: Ensure that the CI869 module
is configured in the Hardware Tree (in the Control
Builder) for that position, and that the configuration is
downloaded to controller.
Possible Cause 2: The CI869 module is just
powered up or it is being configured and
downloaded.
Corrective Action 2: Allow time for the module to
initialize.
Corrective Action 3: If the indication persists after
performing the corrective actions 1 and 2, then one
of the following corrective actions is recommended:
• Remove and insert the CI869 module to the
CEX-Bus and allow time for it to initialize.
• If this CI869 is the only module on the
CEX-Bus, or if the CEX-Bus already contains
other communication modules and all the LED's
on those modules are OFF, then one of the
following corrective actions is recommended:
- Initiate a reset signal (INIT) from the PM8xx
processor unit.
- Check the CEX-Bus fuse inside the PM8xx
processor Unit Adept 05215-110 移动手持示教器 T2 Pendant 10m
| | | |
