125S2193-4 6014BZ10000E 模块备件

产品标题：125S2193-4 6014BZ10000E 数字量美女输入卡 Taylor

产品参数：

型号：125S2193-4 6014BZ10000E

质保：七天验收期，质保期一年

品牌： Taylor
产品图片展示




产品详情资料
PROM校验和验证NVRAM校验和验证DPRAM/SRAM验证处理器指令集测试定时器测试。I/O扩展总线通信安全扩展总线消息完整性通过对每个发送和接收的消息或数据集进行校验和计算来维护。开放输入检测
ASI模块识别并报告以下任何打开的输入：
通过指示这些信道上的不良质量来激活信道。
例外情况是-10至+10 VDC、0至10 VDC和0至
5 VDC输入。报警和异常报告与ASI模块相关的功能代码不会生成报警或异常报告。从在线配置WBPEEUI240774A0 2-11ASI模块输入的值必须输入到标准异常报告块。更多信息请参阅第6节。在线配置期间，可以更改FCs 215、216和217中与ASI模块相关的在线配置规范。当对输入通道参数进行更改时（FC216），通道将在短时间内保持后一个值，在此期间状态保持不变。此保持时间基于在线配置期间更改的通道数。注：计划每个FC 216的保持时间为4秒（坏情况）
在线配置期间。逻辑电源ASI模块从MMU背板接收电源（+5 V）。电源通过ASI模块背面的顶部12针卡边缘连接器（P1）连接。安装硬件协调机架I/O模块和终端单元安装InstandaBB自动化外壳（CAB-01、CAB-04、CAB.12）。单个机柜中可安装的模块数量各不相同。IEMMU11、IEMMU12、IEM
5 VDC inputs.
PROM checksum verification.• NVRAM checksum verification.• DPRAM/SRAM verification.• Processor instruction set tests.• Timer test.I/O Expander Bus Communication SecurityExpander bus message integrity is maintained by checksumcalculations on each transmitted and received message ordataset.Open Input Detection
The ASI module recognizes and reports any open inputs on
active channels by indicating bad quality on these channels.
The exception is for -10 to +10 VDC, 0 to 10 VDC, and 0 to
5 VDC inputs.Alarm and Exception ReportingNo alarm or exception reports are generated by the functioncodes associated with the ASI module. The values inputfrom Online ConfigurationWBPEEUI240774A0 2 - 11the ASI module must be fed to astandardexceptionreportingblock.Refer to Section 6 for more information.Online ConfigurationAll specifications in FCs 215, 216, and217 associated withtheASI module can be changed during online configuration. Whenchanges are made to the input channel parameters (FC216),the channel will hold the last value for a short period, thestatus remains unchanged during this period. This hold time isbased on the number of channels that were changed duringonline configuration.NOTE: Plan on a hold time of four seconds (worst case) foreach FC 216
during online configuration.Logic PowerThe ASI module receives its power (+5 V) from the MMU backplane. Power connects through the top 12-pin card edge connector (P1)at the back of the ASI module.Mounting HardwareHarmony rack I/O modules and termination units mount instandardABB Automation enclosures (CAB-01, CAB-04,CAB-12). The number of modules that can be mounted in asingle cabinet varies.An IEMMU11, IEMMU12, IEM
