ROFBU 367 103 1 R2C COBUX 用于控制器主驱动卡 KEYMILE

产品标题：ROFBU 367 103 1 R2C COBUX 用于控制器主驱动卡 KEYMILE

型号：ROFBU 367 103 1 R2C COBUX 用于控制器主驱动卡

品牌:  KEYMILE

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
H41q-M/H51q-M
单通道中央模块和单通道I/O总线
H41q质谱/H51q质谱
带双处理器，安全相关
单通道中央模块和单通道I/O总线，根据IEC 61508，具有高SIL 3的TüV证书
2.2.2 H41q-H、HS/H51q-H和HS的概念
图3:H41q-H、HS/H51q-H和HS的概念
H41q-H/H51q-H
冗余中央模块和高可用PES的单通道I/O总线
H41q HS/H51q HS，带双处理器，安全相关
冗余中央模块和单通道I/O总线，用于高可用性和安全相关
根据IEC 61508，具有TüV证书的PES达到SIL 3
2.2.3 H41q HR、HRS/H51q HR和HRS的概念
图4:H41q HR、HRS/H51q HR和HRS的概念
I/O总线
I/O总线
CU 2单元
输入模块
中央模块
输出模块
CU 1单元
DPR DPR
特点
CU冗余
单声道I/O模块/
冗余的
I/O总线单声道
I/O总线
I/O总线
CU 2单元
输入模块
中央模块
输出模块
CU 1单元
DPR DPR
I/O总线
I/O总线
特点
CU冗余
I/O模块冗余/
单声道
I/O总线冗余
HIMA PES的概念
6.
H41q人力资源/H51q人力资源
高可用PES的冗余中央模块和双通道I/O总线。
H41q HRS/H51q HRS，带双处理器，安全相关
冗余中央模块和冗余I/O总线，用于高可用性和安全相关PES
根据IEC 61508，具有达到SIL 3的TüV证书
图纸备注：
CU=中央模块
I/O模块=输入/输出模块
I/O总线=输入和输出的总线系统
DPR=双端口RAM
H41q系统系列
7.
3 H41q系统系列
H41q系统系列包括紧凑设计的单通道和冗余PES
型号，还具有TüV安全证书。
所有输入/输出模块都可以与
中央模块。
H41q系统系列的所有模块均满足电磁兼容性要求
根据EG指南89/336/EWG10条的电磁抗扰度
一致性模块数据表中的CE标志证明了这一点。而且
系统和模块都贴有带有此标志的标签。
H41q系统系列的所有型号都将控制任务所需的所有组件集于一身
19英寸子架，5个单元高，带集成电缆槽（另见H41q数据表
系统或装配套件）。
3.1概述H41q-M / H51q-M
single channel central module and single channel I/O bus
H41q-MS / H51q-MS
with double processors, safety-related
single channel central module and single channel I/O bus with TÜV certificate up to SIL 3 according to IEC 61508
2.2.2 Concept of H41q-H, HS / H51q-H, HS
Figure 3: Concept of H41q-H, HS / H51q-H, HS
H41q-H / H51q-H
redundant central modules and a single channel I/O bus for highly available PES
H41q-HS / H51q-HS with double processors, safety-related
redundant central modules and a single channel I/O bus for highly available and safety related
PES with TÜV certificate up to SIL 3 according to IEC 61508
2.2.3 Concept of H41q-HR, HRS / H51q-HR, HRS
Figure 4: Concept of H41q-HR, HRS / H51q-HR, HRS
I/O bus
I/O bus
CU 2
Input modules
Central modules
Output modules
CU 1
DPR DPR
Characteristics
CU redundant
I/O modules mono/
redundant
I/O bus mono
I/O bus
I/O bus
CU 2
Input modules
Central modules
Output modules
CU 1
DPR DPR
I/O bus
I/O bus
Characteristics
CU redundant
I/O modules redundant/
mono
I/O bus redundant
Concept of the HIMA PES
6
H41q-HR / H51q-HR
Redundant central modules and two channel I/O bus for highly available PES.
H41q-HRS / H51q-HRS with double processors, safety-related
redundant central modules and redundant I/O bus for highly available and safety-related PES
with TÜV certificate up to SIL 3 according to IEC 61508
Remarks to the drawings:
CU = central module
I/O modules = input / output modules
I/O bus = bus system for inputs and outputs
DPR = Dual Port RAM
The H41q System Family
7
3 The H41q System Family
The H41q system family comprises compact designed PES in single channel and redundant
models, also with TÜV safety certificate.
All input/output modules can be used with both redundant and single channel models of the
central modules.
All modules of the H41q system family meet the requirements for electromagnetic compatibility
and immunity according to article 10 of the EG guideline 89/336/EWG for the electromagnetic
conformity. This is demonstrated with the CE sign within the data sheets of the modules. Also
the systems and modules are wearing a label with this sign.
All models of the H41q system family have all the components required for control tasks in one
19 inches subrack, 5 units high, with an integrated cable tray (see also data sheets of H41q
systems or assembly kits).
3.1 Overview Assem
