HTB-01-AA HTB-01 HTB 01 伺服驱动器 BAUTZ

产品标题：HTB-01-AA HTB-01 HTB 01 伺服驱动器 BAUTZ

型号：HTB-01-AA HTB-01 HTB 01 伺服驱动器

品牌: BAUTZ

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
所有I/O模块均可在操作期间拆除或插入（见第8.1.1章）。
3.3.3 ATEX（Ex）i模块
当前（Ex）i模块有两种结构模型：
–非清漆，带PCB覆盖层
–涂漆，带PCB覆盖层
任何型号都可以装配在一起，它们之间没有空插槽。
非清漆（Ex）i模块可与非（Ex”i模块组合在一起，无任何限制。左侧或右侧不需要空闲插槽。
对于涂有油漆的（Ex）i模块（PCB覆盖），右侧插槽必须与非（Ex
（M 2214）。这也适用于插槽编号15。（Ex）i模块左侧的插槽可以配备
任何其他模块。备用插槽必须由前板M 2215（4个间隔单元）覆盖
SU）或M 2217（8个间距单位SU）。
带隔板或前板的可用前板：
M 2214带隔板的前板100 x 160 mm
M 2215前板4 SU
M 2217前板8 SU
本质安全电路的电缆插头有标记并有编码插脚，因此它们只能
插入适当的模块。
3.3.4 SIL 3安全相关输出模块
所有安全相关输出模块均符合SIL 3的要求。
安全相关输出模块有三个串联的半导体。那个
这意味着现在安全停机所需的第二个独立部件
集成在输出模块中。
如果输出模块出现故障，则SIL 3的要求有效，无时间限制。在里面
以下这个特性称为集成安全关闭。
如果安全相关输出模块在运行期间出现故障，则它将自动
通过集成安全停机关闭，以获得安全断电状态。
3.3.5输出模块的特殊功能
所有输出模块都具有以下特殊功能：
–为了提高可用性，安全相关输出模块的输出可以
并联开关，无外部二极管。
解耦二极管已经集成在模块上（参见相应数据
表）。
–无输出电压All I/O modules can be removed or inserted during operation (see chapter 8.1.1).
3.3.3 ATEX (Ex)i-Modules
The current (Ex)i modules exist in 2 construction models:
– non-varnished, with PCB covering
– varnished, with PCB covering
Any models can be equipped together without empty slots between them.
Non-varnished (Ex)i modules may combined together with non-(Ex)i modules without any restrictions. There are no free slots necessary on the left or on the right.
With varnished (Ex)i modules with PCB covering the right slot has to remain free in combination with non-(Ex)i modules, or has to be equipped with a front plate with partition plate
(M 2214). This is also valid for slot no. 15. The slot left to the (Ex)i module may be equipped
with any other module. Spare slots have to be covered by front plates M 2215 (4 spacing units
SU) or M 2217 (8 spacing units SU).
Usable front plates with partition or front plates:
M 2214 Front plate with partition plate 100 x 160 mm
M 2215 Front plate 4 SU
M 2217 Front plate 8 SU
Cable plugs for intrinsically safe circuits are marked and have coded pins, so that they can only
be plugged into the appropriate modules.
3.3.4 Safety-Related Output Modules for SIL 3
 All the safety-related output modules meet the requirements of SIL 3.
The safety-related output modules have three semiconductors connected in series. That
means that more than the required second independent component for safety shutdown is now
integrated in the output module.
In case of a fault of an output module the requirements of SIL 3 are valid without time limit. In
the following this feature is called the integrated safety shutdown.
If a safety-related output module should fail during operation then it will be automatically
switched off by the integrated safety shutdown to get the safe de-energized status.
3.3.5 Special Features of the Output Modules
All output modules have the following special features:
– To increase the availability the outputs of the safety-related output modules can be
switched in parallel without external diodes.
Decoupling diodes are already integrated on the module (see the corresponding data
sheets).
– No output voltage
