IS215UCVEH2AF VMICPCI-7614-132 模拟量控制驱动卡 GE 通用电气

产品标题：IS215UCVEH2AF VMICPCI-7614-132 模拟量控制驱动卡 GE 通用电气

型号：IS215UCVEH2AF VMICPCI-7614-132 模拟量控制驱动卡

品牌:   GE 通用电气

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
–电缆插头的设计可实现致动器的两极连接。在一起
通过输出模块的两极电源，接地故障检测将简化为
整体式电流互感器。
电缆插头有两种规格：
•L-在电缆插头中，一极与公共L-
•L-2极型，2极，每个通道带L
另见10.13.6章，“电缆插头订购代码说明”，选项P2
•输出模块故障时无时间限制操作。
3.4系统电压24 VDC
HIMA系统将连接至24 VDC。连接端子标有L+和
L-。HIMA提供的电源装置，例如电源PS1000，满足
符合CE关于电气安全和EMC的要求。
所有使用的电源必须满足SELV（安全特低电压）或PELV的要求
（保护超低电压）。另见6.4章。
电源装置符合NAMUR NE 21建议的要求
短时电压下降至20ms时的安全性。
用于提供24 V电源，无法保证在电压骤降期间的缓冲
至少20ms，H41q系统系列必须采取以下措施：
•中央单元电源的去耦，以及
•噪音消除（可参数化）。
注：由于灯具的涌入电流较高
必须考虑灯负载的电源装置。
H41q系统系列
12
H51q系统系列
13
4 H51q系统系列
H51q系统系列包括模块化设计的单通道和冗余PES
型号，还具有TüV安全证书。
所有输入/输出模块都可以与
中央设备。
H51q系统系列的所有模块均满足电磁兼容性要求
以及符合欧盟电磁指南89/336/EWG10条的抗扰度
一致性这在模块数据表中用CE标志标记。此外
系统和模块都贴有带有此标志的标签。
H51q系统系列包括一个19英寸中央机架，5个单元高，多16个输入端/
输出机架尺寸为19英寸，4个单元高（另请参阅H51q系统或组装套件的数据表）。
4.1 H51q组装套件概述
工作系统所需的部件包括在装配套件中：– The design of the cable plugs enables the two-pole connection of the actuators. Together
with a two-pole supply of the output module an earth fault detection will be simplified by
means of a totalizing current transformer.
The cable plugs are available in two specifications:
• L- in cable plug, one-pole with common L-
• L- in 2-pole type, 2-pole with L- per channel
see also chapter 10.13.6 , “Description of the Order Code for Cable Plugs”, option P2
• No time-limited operation in case of a faulty output module.
3.4 System Voltage 24 VDC
HIMA systems will be connected to 24 VDC. The connection terminals are labelled with L+ and
L-. The power supply units made available by HIMA, e.g. the power supply PS1000, meet the
requirements according to CE for electrical safety and EMC.
All used power supplies must fulfill the requirements SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage). See also chapter 6.4.
The power supply units meet the requirements of the NAMUR recommendation NE 21 for the
safety during short-time voltage dips up to 20 ms.
For the supply of 24 V sources, which cannot guarantee a buffering during voltage dips of at
least 20 ms, the following measures must be taken in the H41q system family:
• decoupling of the power supply for the central units and
• noise blanking (parameterizable).
Note Due to the high inrush current of lamps the correct dimensioning of the
power supply units for lamp loads must be regarded.
The H41q System Family
12
The H51q System Family
13
4 The H51q System Family
The H51q system family comprises modular designed PES in single channel and redundant
models, also with TÜV safety certificate.
All input/output modules can be used with both redundant and single channel models of the
central devices.
All modules of the H51q system family meet the requirements for electromagnetic compatibility
and immunity according to article 10 of the EU guideline 89/336/EWG for the electromagnetic
conformity. This is marked with the CE sign within the data sheets of the modules. Also the
systems and modules are wearing a label with this sign.
The H51q system family consists of one 19 inches central rack, 5 units high, and up to 16 input/
output racks in the 19 inches size, 4 units high (see also data sheets for H51q systems or assembly kits).
4.1 Overview Assembly Kits H51q
The components required for a working system are included in assembly kits:
