ABB 用于实时加速器RTA卡件 PU515 3BSE013063R1

产品标题：ABB 用于实时加速器RTA卡件 PU515 3BSE013063R1

型号： 用于实时加速器RTA卡件 PU515 3BSE013063R1

品牌:ABB

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
对于I/O子架，I/O总线的连接元件是F 7553耦合模块
插入插槽17。单个I/O模块子架之间的I/O总线连接
通过连接到插头的BV 7032数据电缆在后侧建立
XD.1和XD.2。I/O模块框中的I/O总线集成在总线板中。
F 7546总线终端模块插入后一个I/O模块的XD.2连接器
子机架以终止I/O总线。
4.3.6输入/输出模块
I/O模块用于设备和
中央设备。输入和输出电路始终通过电缆馈入I/O模块
前面的插头。数字信号的状态显示在电缆的LED上
插头。电源可以通过电缆插头，也可以通过I/O总线板。的顺序
不同的I/O模块类型并不重要。
操作期间，所有I/O模块都可以拔出或插入（见第8.1.1章）
4.3.7 ATEX（Ex）i模块
当前（Ex）i模块有两种结构模型：
–非清漆，带PCB覆盖层
–涂漆，带PCB覆盖层
任何型号都可以装配在一起，中间没有空闲插槽。
非清漆（Ex）i模块可与非（Ex”i模块组合在一起，无任何限制。此外，左侧或右侧不需要空闲插槽。
对于涂有油漆的（Ex）i模块（PCB覆盖），右侧插槽必须与非（Ex
（M 2214）。这也适用于插槽15。留给（Ex）i模块的插槽可能配备
任何其他模块。备用插槽必须由前板M 2215覆盖（4个间隔单元SU）
或M 2217（8个间距单位SU）。
可用隔板和前板：
M 2214带隔板的前板100 x 160 mm
M 2215前板4 SU
M 2217前板8 SU
本质安全电路的电缆插头有标记并有编码插脚，因此它们只能
插入适当的模块。
4.3.8 SIL 3安全相关输出模块
所有安全相关输出模块均符合SIL 3的要求。
安全相关输出模块有三个串联的半导体。那个
这意味着现在安全停机所需的第二个独立部件
集成在输出模块中。
如果输出m出现故障With the I/O subrack, the connection element for the I/O bus is the F 7553 coupling module
plugged into slot 17. The connection of the I/O bus between the individual I/O module subracks
is established at the rear side via the BV 7032 data cable which is connected to the plugs
XD .1 and XD .2. The I/O bus in the I/O module subracks is integrated in the bus board.
An F 7546 bus termination module is plugged into the XD .2 connector of the last I/O module
subrack to terminate the I/O bus.
4.3.6 I/O Modules
The I/O modules are used for signal transfer and signal matching between the plant and the
central devices. The input and output circuits are always fed into the I/O modules via cable
plugs on the front side. The status of the digital signals is shown on the LEDs of the cable
plugs. The power supply is either via the cable plugs or via the I/O bus board. The order of the
different I/O module types does not matter.
All I/O modules can be pulled out or inserted during operation (see chapter 8.1.1)
4.3.7 ATEX (Ex)i-Modules
The current (Ex)i modules exist in two construction models:
– non-varnished, with PCB covering
– varnished, with PCB covering
Any models can be equipped together without free slots between.
Non-varnished (Ex)i modules may combined together with non-(Ex)i modules without any restrictions. Also no free slots are necessary on the left or on the right.
With varnished (Ex)i modules with PCB covering the right slot has to remain free in combination with non-(Ex)i modules or has to be equipped with a front plate including partition plate
(M 2214). This is also valid for slot 15. The slot left to the (Ex)i module may be equipped with
any other module. Spare slots have to be covered by front plates M 2215 (4 spacing units SU)
or M 2217 (8 spacing units SU).
Usable partition plates and front plates:
M 2214 Front plate with partition plate 100 x 160 mm
M 2215 Front plate 4 SU
M 2217 Front plate 8 SU
Cable plugs for intrinsically safe circuits are marked and have coded pins, so that they can only
be plugged into the appropriate modules.
4.3.8 Safety-Related Output Modules for SIL 3
All the safety-related output modules meet the requirements of the SIL 3.
The safety-related output modules have three semiconductors connected in series. That
means that more than the required second independent component for safety shutdown is now
integrated in the output module.
In case of a fault of an output m
