LP10-11U 用于工业驱动器主机带多路接口 GE 通用电气

产品标题：LP10-11U 用于工业驱动器主机带多路接口 GE 通用电气

型号： LP10-11U 用于工业驱动器主机带多路接口

品牌:  GE 通用电气

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
输出模块的特殊功能
所有输出模块都具有以下特殊功能：
–为了提高可用性，安全相关输出模块的输出可以
并联开关，无外部二极管。
解耦二极管已经集成在模块上（参见相应数据
表）。
–如果输出模块的电源电压L-被切断，则不会产生输出电压。
–电感负载的连接可以在线圈上不使用保护二极管的情况下完成。
然而，建议在电感负载处直接连接二极管，以避免
噪声电压。
–指示输出状态的LED单独控制。
–电缆插头的设计可实现致动器的两极连接。在一起
通过输出模块的两极电源，接地故障检测将简化为
整体式电流互感器。
电缆插头有两种规格：
•L-在电缆插头中，一极与公共L-
•L-2极型，2极，每个通道带L
另见10.13.6章，“电缆插头订购代码说明”，选项P2
–输出模块出现故障时，无时间限制操作。
4.4系统电压24 VDC
HIMA系统将连接至24 VDC。连接端子标有L+和
L-。HIMA提供的电源装置，例如电源PS1000，满足
符合CE关于电气安全和EMC的要求。
所有使用的电源必须满足SELV（安全特低电压）或PELV的要求
（保护超低电压）。另见6.4章。
电源装置符合NAMUR NE 21建议的要求
短时电压下降至20ms时的安全性。
用于提供24 V电源，无法保证在电压骤降期间的缓冲
H51q系统系列必须采取以下措施：
•中央单元电源的去耦，以及
•噪音消除（可参数化）。
注：由于灯具的涌入电流较高
必须考虑灯负载的电源装置。Special Features of the Output Modules
All output modules have the following special features:
– To increase the availability the outputs of the safety-related output modules can be
switched in parallel without external diodes.
Decoupling diodes are already integrated on the module (see the corresponding data
sheets).
– No output voltage is generated if the supply voltage L- is cut at the output module.
– The connection of inductive loads can be done without using protection diodes at the coil.
However, it is recommended to connect a diode directly at the inductive load avoiding
noise voltages.
– The LED signaling the output status is controlled separately.
– The design of the cable plugs enables the two-pole connection of the actuators. Together
with a two-pole supply of the output module an earth fault detection will be simplified by
means of a totalizing current transformer.
The cable plugs are available in two specifications:
• L- in cable plug, one-pole with common L-
• L- in 2-pole type, 2-pole with L- per channel
see also chapter 10.13.6, “Description of the Order Code for Cable Plugs”, option P2
– No time-limited operation in case of a faulty output module.
4.4 System Voltage 24 VDC
HIMA systems will be connected to 24 VDC. The connection terminals are labelled with L+ and
L-. The power supply units made available by HIMA, e.g. the power supply PS1000, meet the
requirements according to CE for electrical safety and EMC.
All used power supplies must fulfill the requirements SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage). See also chapter 6.4.
The power supply units meet the requirements of the NAMUR recommendation NE 21 for the
safety during short-time voltage dips up to 20 ms.
For the supply of 24 V sources, which cannot guarantee a buffering during voltage dips of at
least 20 ms, the following measures must be taken in the H51q system family:
• decoupling of the power supply for the central units and
• noise blanking (parameterizable).
Note Due to the high inrush current of lamps the correct dimensioning of the
power supply units for lamp loads must be regarded.
