IS200ISBAH1ABB IS215ACLIH1AP 用于控制器模块 GE 通用电气

产品标题：IS200ISBAH1ABB IS215ACLIH1AP 用于控制器模块 GE 通用电气

型号：IS200ISBAH1ABB IS215ACLIH1AP 用于控制器模块

品牌:   GE 通用电气

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料

必须检查需要通过后部PCB总线馈电的此类模块的插槽。
9.6.4打开HIMA PES
连接工作电压后，HIMA PES进入RUN运行，如果
用户程序已加载，系统中未发现错误。
如果显示STOP（停止），程序可以通过ELOP II（运行状态）启动。如果出现以下情况，则会出现错误
这是不可能的。只有在纠正错误后，例如设置正确的开关位置，
正确的连接线，或者可能在更换模块等之后，RUN操作是
起动。
可以通过两个按钮或
通过OLT窗口开始与编程设备通信后。请参阅
操作系统文档。
9.6.5启动编程设备和PES之间的通信
关于编程设备与PES之间通信的构建和启动：请参阅文档一步ELOP II、用户手册操作系统和用户手册
ELOP II资源类型。
通信故障可以通过监控、记录程序（HIKA）进行检查
并对数据通信进行了分析。
有关工具“HIKA”的更多信息，请参阅HIMA服务。
9.7维护
在安全相关应用中，例如使用继电器输出模块时，必须定期对模块进行检修（继电器模块每3年，所有其他模块每10年
年，脱机验证试验，见IEC/EN 61508-4，3.8.5段）。
我们建议每五年更换一次电源中的电解电容器。
耦合模块F 7553（仅
H51q系统）
编码机架的开关位置
到资源类型
接线，尤其是看门狗信号，
请参阅组装套件的数据表
和安全手册
电源线、信号线和数据线的维护只能由以下人员执行
考虑所有ESD保护措施的合格人员。
在直接接触这些线路之前，维护人员必须
静电放电！
启动和维护
42
9.7.1更换缓冲电池
缓冲时使用锂电池。
缓冲电池的寿命（CPU不工作，模块无电压馈电）：
TA=25°C时1000天，
TA=60°C时200天
建议更换缓冲电池（CPU正在运行，模块有电压
喂养）迟在6年后。
更换H41q/H51q系统的外部电池：
1.无焊片电池：
CR-1/2 AA-CD，HIMA零件号440000019。
拆下蓄电池盖，将蓄电池从支架上松开，然后插入新蓄电池。检查极性！
2.带焊片的电池电 slots of such modules, which need the feeding via the rear PCB bus, has to be checked.
9.6.4 Switching on the HIMA PES
After the operating voltage has been connected, the HIMA PES goes into RUN operation, if
the user program has been loaded and no error has been found in the system.
If STOP is displayed the program can be started via ELOP II (RUN state). There is an error if
this is not possible. Only after the correction of the error, e.g. setting the correct switch position,
correct connecting lines, or possibly after the exchange of a module etc. the RUN operation is
started.
Error displays can be called on the diagnostic display of the central module via two buttons or
after the start of the communication to the programming device via OLT window. Refer to the
documentation of the operating system.
9.6.5 Starting the Communication between Programming Device and PES
For construction and startup of the communication between progamming device and PES: refer to the documentations first steps ELOP II, user manual operating system and user manual
ELOP II Resource Type.
Communication faults can be checked by means of a program (HIKA) for monitoring, logging
and analyzing of the data communication.
For more informations about the tool “HIKA” refer to the HIMA service.
9.7 Maintenance
At safety-related applications, e.g. using of relay output modules, the modules have to be overhauled at regular intervals (every 3 years for relay modules, for all other modules every 10
years, OFFLINE proof test, see IEC/EN 61508-4, paragraph 3.8.5).
We recommend exchanging electrolytic capacitors in the power supply every five years.
Coupling module F 7553 (only
H51q systems)
switch position for coding the rack according
to the resource type
Wiring, especially the watchdog signal,
refer to data sheets of the assembly kits
and the safety manual
Maintenance on supply, signal and data lines may only be executed by
qualified personnel with consideration of all ESD protection measures.
Before direct contact of these lines the maintenance personnel has to
be electrostatically discharged!
Startup and Maintenance
42
9.7.1 Exchange of the Buffering Batteries
For buffering lithium batteries are used.
Lifetime of the buffer batteries (CPU not in operation, modules without voltage feeding):
1000 days at TA = 25 °C,
 200 days at TA = 60 °C
It is recommended to change the buffer batteries (CPU in operation, modules with voltage
feeding) at the latest after 6 years.
Changing of external batteries of the systems H41q/H51q:
1. Battery without soldering lug:
CR-1/2 AA-CD, HIMA part no. 440000019.
Remove battery cap, loose battery out of the holder and plug in new battery. Check the polarity!
2. Battery with soldering lug
