HSE40/100GETSP1-01 用于控制线速以太网/IP测试模块 IXIA

产品标题：HSE40/100GETSP1-01 用于控制线速以太网/IP测试模块 IXIA

型号：HSE40/100GETSP1-01 用于控制线速以太网/IP测试模块

品牌: IXIA

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
在冗余系统交换中央模块后，必须加载用户程序
必须考虑以下因素：
–用户程序可以通过“自我教育”程序加载到冗余系统
（另请参阅操作系统手册中的说明和相应数据
CPU表）。
–确保加载正确的中央模块
–此外，运行的中央模块中现有用户程序的代码版本
并且要加载到更改后的模块中的用户程序必须相同。
9.8.2输入/输出模块故障
PES在以下过程中自动识别安全相关输入/输出模块中的故障
操作，它们通过I/O错误显示在诊断显示器上，并指示
故障位置。
如果输入/输出模块有线路监控，则传感器和致动器的馈线也会受到监控
检查并在诊断显示屏上显示故障
频道编号。在这种情况下，还必须检查外部接线，但模块必须
不可更改。
非安全相关输入/输出模块的故障通道的影响将是不同的
逻辑中的信号状态与电缆连接器上的相关LED之间。
如果逻辑信号与LED显示屏不匹配，则相应的输入/输出模块必须
交换了。对于输出模块，应首先检查控制元件是否工作或
线路干扰。
在操作过程中，可以插入和拉出输入/输出模块。有关输入/输出模块的插入和拆卸，请参阅第8.1.1章。
启动和维护
44
9.8.3协处理器和通信模块故障
模块故障由前LED（接口LED或ERR LED）发出信号。相应的功能块通过系统变量通知用户程序。为了维护
必须立即更换H41q和H51q系统故障协处理器或通信模块的冗余。更换冗余系统中的故障模块（两个
中央模块）在系统运行期间，必须遵守以下程序：
1.拆卸中央模块固定螺钉。
2.必须拆下相关的中央模块。
3.拆下待更换模块的固定螺钉。
4.必须拆除有缺陷的协处理器模块或通信模块。
5.必须拔下所有接口电缆，包括冗余电缆。
6.在更换有缺陷模块的模块上，所有开关必须设置为
相同的位置。
7.必须插入所有接口电缆，包括冗余电缆。
8.必须插入交换机中的协处理器或通信模块。
9.固定更换模块的安装螺钉。
10.相关中心e user program has to be loaded after exchanging the central module at redundant systems
the following has to be regarded:
– the user program can be loaded at redundant systems via the procedure "Self-education"
(see also the description in the operating system manual and the corresponding data
sheet of the CPU).
– make sure that the correct central module will be loaded
– additionally the code version of the existing user program in the running central module
and the user program to be loaded in the changed module must be the same.
9.8.2 Faults in the Input/Output Modules
Faults in safety-related input/output modules are recognized automatically by the PES during
operation, and they are displayed on the diagnosis display by I/O error with the indication of
the faulty position.
If an input/output module has a line monitoring also the feeding lines to sensors and actuators
are checked and faults are indicated on the diagnosis display additionally with the defective
channel number. In this case also the external wiring has to be checked but the module must
not be changed.
The effect of faulty channels of not safety-related input/output modules will be the difference
between the signal status in the logic and of the appertaining LEDs on the cable connectors.
If the logic signal does not match the LED display, the respective input/output module must be
exchanged. For output modules you should first check whether the control element works or
there is a line disturbance.
Input/output modules can be inserted and pulled out during operation. For insertion and removing of input/output modules refer to chapter 8.1.1.
Startup and Maintenance
44
9.8.3 Faults in the Coprocessor and Communication Modules
Faults of the modules are signaled by front LEDs (interface LED or ERR LED). The corresponding function block informs the user program via system variables. In order to maintain
the redundancy of the H41q and H51q systems faulty coprocessor or communication modules have to be changed immediately. To change faulty modules in a redundant system (two
central modules) during operation of the system the following procedure must be observed:
1. Remove fixing screw of the central module.
2. The related central module has to be removed.
3. Remove fixing screw of the module to be changed.
4. The defective coprocessor module or communication module has to be removed.
5. All interface cables including cable for redundancy have to be unplugged.
6. On the module in exchange for the defective module all switches have to be set exactly to
the same positions.
7. All interface cables including cable for redundancy have to be plugged in.
8. The coprocessor or communication module in exchange has to be plugged in.
9. Fix the mounting screw of the changed module.
10.The related central
