PFVI401 3BSE018732R1 用于驱动控制数字扩展卡 ABB

产品标题：PFVI401 3BSE018732R1 用于驱动控制数字扩展卡 ABB

型号：PFVI401 3BSE018732R1 用于驱动控制数字扩展卡

品牌：  ABB

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料



图2-21显示了“树形”配置的Advant Fieldbus 100。与的规则相同
计算电缆长度时，图2-20有效。的区别是这两个车站
计算中使用的距离大。
由此，我们得到了以下限制：
A+B+C+D+E<=1400米（4500英尺）和
A+B+C+F+G+H<=1400米（4500英尺）和
E+D+F+G+H<=1400米（4500英尺）和
A、 （C+F）、E、H<=700米（2300英尺）（对于RG 11）或300米（1000英尺）（针对RG59和
D、 G<=750米（2500英尺）。注意！该公式也适用于8500和15000米配置，参见
1.8.2章Advant Fieldbus 100长度概念
支持这些长度的设备。
Artisan Technology Group-质量仪器…保证|（888）88-SOURCE | www.artistg.com
Advant®Fieldbus 100用户指南
2.8.3节计算Advant Fieldbus 1003BSE 000 506R701 2-23150米（500英尺）介质的大总线长度
Artisan Technology Group-质量仪器…保证|（888）88-SOURCE | www.artistg.com
Advant®Fieldbus 100用户指南
2章先进的现场总线100概念
NOTE!
This formula is applicable also for 8,500 and 15,000 meter configurations, see
Chapter 1.8.2 Advant Fieldbus 100 length concept for information about
equipment supporting these lengths.
When using Advant Fieldbus 100 in “tree” configuration the bus length is the distance between
the two stations on the bus that is most far apart.This means that a number of length between
different combination of pairs of stations must be taken into consideration in order to decide
which two station that is most far apart. The same roles regarding calculating methods for bus
length as well possible length is valid both for star configuration as well as the common bus
configuration.
The Figure 2-21 shows an Advant Fieldbus 100 in a “tree” configuration. The same rules as for
Figure 2-20 is valid when calculating the cable length. The only difference is that the two stations
that is most far apart is to been used in the calculation.
By this, we got the following restrictions:
A + B + C + D + E <= 1,400 meters (4,500 ft) and
A + B + C + F + G + H <= 1,400 meters (4,500 ft) and
E + D + F + G + H <= 1,400 meters (4,500 ft) and
A, (C + F), E, H <= 700 meters (2,300 ft) for RG 11 or 300 meters (1,000 ft) for RG59 and
D, G <= 750 meters (2,500 ft).NOTE!This formula is applicable also for 8,500 and 15,000 meter configurations, see
Chapter 1.8.2 Advant Fieldbus 100 length concept for information about
equipment supporting these lengths.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Advant® Fieldbus 100 User’s Guide
Section 2.8.3 Calculation of Maximum Bus Length for the Advant Fieldbus 1003BSE 000 506R701 2-23150 meter (500 ft)of media
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Advant® Fieldbus 100 User’s Guide
Chapter 2 Advant Fieldbus 100 Concepts
2-24 3BSE 000 506R701
2.9 Transmission Principles
