W2=导体温度Tº时导体的等效重量Non-level spans shall only be used as sagging spans when there are no level spans between
stringing points. Sags for non-level spans are determined by means of the “Non-Level Span
Sag Formula” given in Drawing 11.3 which express the sag in terms of the sag of a level
span of the same length. The same method as for measuring sag specified in section 16.4 is
used except the vertical distances between the sag lath and the point at which the conductor
runs through the stringing block shall be the values calculated from the non-level span sag
formulas.11.6 BindingWhen the sagging operation is finished, the conductor is transferred to the insulators and the
conductors terminated. The post type insulators shall be tightened on the pins. The
conductors are placed in the top groove of post insulators on IMP structures. Top ties should
be used with armour rods on these poles and the lay direction of the tie must be the same as
الشرآة السعودية للكهرباء Company Electricity Saudi
SDCS-01 SEC DISTRIBUTION CONSTRUCTION STANDARDDATE: October 2004GPage 25 of 30the lay direction of the outer strands of the conductor. For LAP structures, the conductors
shall be placed on the side of the post insulators and side ties with armour rods should be
used.11.7 Taps and Jumper Connections
Jumpers and other leads connected to the line conductors shall have sufficient slack to allow
free movement of the conductors. Where slack is not shown on construction drawings, it
will be provided by at least two bends in a vertical plane, or one in a horizontal plane, or the
equivalent. In areas where Aeolian vibration occurs, special measures to minimize effects of
jumper breaks shall be used as specified.
Parallel groove compression type connectors shall be used as connectors. Bolt type parallel
grove connectors shall be used only at terminal locations. An approved oxide inhibitor shall
be applied after cleaning the conductor surface by wire brush.
11.8 Sag and Tension Calculation
F = Stress at T º conductor temperature
F01 = Initial Stress at T01º conductor temperature such as at extreme condition
L = Ruling span
E = Modulus of Elasticity
a = Coefficient of Elasticity
W1 = Equivalent weight of conductor at T01º conductor temperature
W2 = Equivalent weight of conductor at T º conductor temperature
