产品标题：ABB DSTA156B 3BSE018310R1   数字量控制卡

型号：ABB DSTA156B 3BSE018310R1

品牌：ABB

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
 TER-FOLLOWER的方式控制。
用于此类系统的驱动器类型相同，可能在以下方面有所不同
但将由同一网络供电。他们的号码
通常不受限制。
从控制的角度来看，不同的条件和需求
需要匹配。
示例可从ABB自动化产品公司索取
股份有限公司。
-连接的高功率驱动器的典型配置
12脉冲并行主跟随器应用
（见第3.6章）
此配置显示12脉冲并行驱动系统。它是一个
增加驱动系统功率的简单选项。取决于
工程特点、冗余或紧急操作，如果
一个转换器故障，可用。
这种驱动器使用两个相同的6脉冲转换器，特别是
设计扼流圈称为T型电抗器或12脉冲扼流环或接口
核反应堆转换器由一个12脉冲线路变压器供电
相位置相差
30°标高。
例如变压器配置Ì//\204。这
配置降低了级别和订单数量
交流侧谐波。只有11号和13号，23号和25号，
第35个a.s.o.已经存在。直流侧谐波为
也减少了，从而提高了效率。（现场电源不
如接线图3.6所示。取决于现场电源
选定，网络连接、联锁和
控制连接可以取自任何其他接线图
显示选定的现场供应。）
无法将两个12脉冲系统（2个转换器、Treactor和1个电机）连接到一个12脉冲变压器。
有关更多信息，请参阅手动12脉冲操作。
图3/3：两个机械连接电机的应用
-连接的高功率驱动器的典型配置
主从动件应用（两个电机，一个公共
轴）
如果两台电机必须共用
位置相差30°el。
每个电机都连接到自己的转换器和现场电源。这个
转换器交换信号以确保每个电机占一半
负载的。
这种配置与标准12脉冲应用在电网谐波方面具有相同的优势（见下文
项目），但不需要T型电抗器。
根据机械配置，调试人员需要一些经验来相应地调整控制- Drives connected in Master-Follower application
If motors have to run with the same speed / torque they are often
controlled in a way called MASTER - FOLLOWER.
Drives used for such systems are of the same type and may differ in
power, but will be supplied from the same network. Their number
normally is not limited.
From the control point of view different conditions and demands
need to be matched.
Examples are available on request from ABB Automation Products
GmbH.
 - Typical configuration for high power drives connected in
12-pulse parallel Master-Follower application
(see chapter 3.6)
This configuration shows a 12-pulse parallel drive system. It is an
easy option to increase the power of a drive system. Depending on
the engineering features , redundancy or emergency operation, if
one converter fails, is made available.
Such drives use two identical 6-pulse converters and an especially
designed choke called T-reactor or 12-pulse choke or interface
reactor. The converters are fed by a 12-pulse line transformer with
separated secondary windings whose phase positions differ by
30°el.
An example is the transformer configuration Ì/ /Ì. This
configuration gives a reduced level and a reduced order number of
harmonics on the AC side. Only the 11th and 13th, the 23rd and 25th,
the 35th a.s.o. are existing. The harmonics on the DC side are
reduced too, which gives a higher efficiency. (The field supply is not
shown on the wiring diagram 3.6. Depending on the field supply
selected, the connections to the network, the interlocking and the
control connections can be taken from any other wiring diagram
showing the selected field supply.)
It is not possible to connect two 12-pulse systems (2 converters, Treactor and 1 motor) to one 12-pulse transformer.
For more information, please see manual 12-pulse operation.
Figure 3/3: Application with tw ors with one common
shaft)
This configuration is often used, if two motors have to share the
load half and half. They are mechanically fixed to each other via a
gearbox or any other device. The converters are fed by a 12-pulse
line transformer with separated secondary windings whose phase
positions differ by 30°el.
Each motor is connected to its own converter and field supply. The
converters exchange signals to make sure, that each motor takes half
of the load. missioning personal needs some experience to adapt control accordingly
