ABB使用配置教程ABB YPM105A YT204001-BH 主板

产品标题：ABB YPM105A YT204001-BH  特惠数字量控制卡

型号：ABB YPM105A YT204001-BH 主板

品牌：ABB

质保：七天验收期，质保期一年
发货期：1-3个工作日

产品图片展示

产品详情资料
 .1/1•电源
有几个组件需要电源。由于布线的先决条件必须考虑在内：-转换器的电源部分：200 V至500 V，取决于转换器类型；见第2章
-转换器的电子电源：仅使用230 V的可能性，由跳线选择
-变频器冷却风扇：230V 1-ph；见技术数据
-电源部分现场电源：200V至500V；见第2章和/或技术数据
-电机冷却风扇：根据电枢供电电压选择电机电压
-继电器逻辑：选择230 V的元件！
此配置与图3.1/1所示的配置基本相同。请检查F1的尺寸，以了解额外负载，如磁场和电机风扇。全部的
组件要么选择230V，要么设置为230V，以便能够组合它们并通过辅助电源供电。不同的消费者
单独熔断。
•控制和安全
继电器逻辑可分为三部分：a： ON/OFF和START/STOP命令的生成：与图3.1/1相同b： 控制和监测信号的生成：主电源接触器K1的操作方式与图3.1/1相同。磁场和电机风扇电源在K1的输出端拾取。因此所有3个用户都以相同的方式进行控制。
未考虑风扇监控。因此，必须进行以下参数设置：
连接（默认）必须更改为：910从10701 10908
 rive configuration using the internal field with reduced external componentsWiring the drive according to this diagram gives the same control performance, but a lower degree of flexibility and nearly no external
monitoring functions done by the drive. The software has to be adapted to the external wiring.Communication
board (COM-x) Control board (CON-2)Power supply
(POW-1)Convertermodule
ONOFF STOPSTART
Field exciter unit
(SDCS-FEX-1/2)
depending on the unit type
an other configuration is possible
the polarities are shown for motor operation if there are intermediate terminalse.g. Pressure
switch at C4module
• Selection of componentssame as figure 3.1/1• Power supply
There are several components, which need a power supply. Because of the wiring preconditions have to be taken into account:
- Converter´s power part: 200 V to 500 V, depending on converter type; see chapter 2
- Converter´s electronics power supply: use only 230 V possibility, selected by jumper
- Converter cooling fan: 230V 1-ph; see Technical Data
- Power part field supply: 200 V to 500 V; see chapter 2 and / or Technical Data
- Motor cooling fan: select the motor voltage acc. to the voltage used for the armature supply
- Relay logic: select the components for 230 V!
This configuration is basically identical to the one shown at figure 3.1/1. Please check the sizing of F1 for the additional load like field and motorfan. All
components are either selected for 230V or set to 230V to be able to combine them and to supply them by an auxiliary power supply. The different consumersare fused separately.
• Control and safety
The relay logic can be split into three parts:
a: Generation of the ON/OFF and START/STOP
