ABB YPK114B 3ASD399002C4 优势产品如何使用

产品标题：ABB YPK114B 3ASD399002C4
产品型号：ABB YPK114B 3ASD399002C4
品牌：ABB
发货期：1-3个工作日，具体可联系客服
质保：质保期一年！

产品图片展示

产品详情资料


•手动送丝
•火炬的机械清洁。
联锁图37显示了PIB联锁系统的组成。
如果国家法规要求电源也应联锁，则
联锁系统可以通过继电器打开
电源。
手动送丝通过焊炬或送丝装置的按钮手动送丝
在不压紧夹紧装置的情况下，每根导线多可馈电6米
分钟只要按下按钮，速度就会增加。碰撞检测机器人功能在A314E/316E/324EL系统上设置为标准功能。安全托架机械安全托架作为选装件订购。
安装安全支架时，以下描述碰撞传感器7.3.3适用。重要的PIB上的机械安全支架功能必须通过连接停用
+24V至PIB输入TB 6.2。
缺少此信号将被PIB解释为碰撞，送丝将被阻塞。Bridge By2，在送丝时已准备好，交付时未安装安全支架。请参见19页的注释2图13，重要提示！安装安全支架时，Bridge By2必须打开。参见注释2图13
19页PIB设计用于带有碰撞传感器的焊炬。在正常状态下，传感器向PIB输入TB6.2.提供24V DC。碰撞传感器控制PIB中的Run Chain继电器。继电器为双极型，集成在机器人的通用停止链（G-stop）中。在正常状态下，继电器处于活动状态。
当碰撞传感器启动时
当碰撞传感器激活时，运行链继电器打开，导致G停止链打开，导致运动快速停止，因为
机器人从操作模式进入待机模式。错误消息G-stop出现
在机器人编程单元上。消息将一直保持，直到通过OK（确定）按钮确认为止。
碰撞后的操作要使机器人再次运行，必须首先
关闭如果火炬偶尔偏离位置，但又弹回来，Gstop链条闭合，机器人准备再次使用。如果焊炬保持在错误位置，例如与焊接物体、夹具等碰撞后，必须移动机器人以使焊炬弹回。ABB馈线装置A-314的前部有一个回弹装置
用于此目的的按钮（重置）。The Collision detection robot function is set as standard on the A314E/316E/324EL systems.Safety bracketThe mechanical safety bracket is ordered as an option.
The following description Collision Sensor 7.3.3 applies when the safety bracket isinstalled.Important!The mechanical safety bracket function on PIB must be deactivated through the connection
of +24V to PIB input TB 6.2.
A lack of this signal will be interpreted as a collision by PIB and the wire feed will beblocked.Bridge By2, in the wire feed is prepared for this and on delivery is made when a safetybracket is not installed. See note 2 Figure 13. on page 19.mportant!Bridge By2, must be open when the safety bracket is installed. See note 2 Figure 13. on
page 19The PIB is designed to be used with a welding torch with collision sensor.In normal status the sensor is to supply 24V DC to the PIB input TB6.2.The collision sensor controls the Run Chain relay in the PIB. The relay is of the twopole type and is integrated in the general stop chain (G-stop) of the robot. In normalstatus the relay is active.
When the collision sensor is activated
When the collision sensor is activated the Run Chain relay opens, resulting in anopened G-stop chain, leading to quick-stop of the motion due to the fact that the
robot goes from operation mode to stand-by mode. The error message G-stop comes
up on the robot programming unit. The message remains until it has been acknowledged by way of the OK button.
Operation aftercollisionTo enable putting the robot into operation again the G-stop chain must first be
closed.If the torch has occasionally been out of position but has sprung back again, the Gstop chain closes and the robot is ready to be used again.If the torch remains in the wrong position, for example after having collided withthe weld object, the fixture, etc., the robot must be moved in order to make the torchspring back. On the front of the ABB wire feed units A-314 there is a spring-back
push-button (reset) for this purpose.Moving parts which according to the EU machinery directives might cause personal
injury are interlocked via the robot holding device and emergency circuit.
Such functions are:
• Manual wire feed
• Mechanical cleaning of the torch.
Interlocking Figure 37. shows the build-up of the PIB interlocking system.
If national regulations require that also the power source shall be interlocked, the
interlocking system can be completed by a relay opening the control circuit of the
power source.
Manual wire feed On manual wire feed via the welding torch or the push-button of the feed unit, the
wire can be
