ABB AINT-02C 原装询价用于控制主板

产品图片展示

产品详情资料
 （XS3/XT3端子A15、B15、A16、B16、C16）。
如果所有I/O通道都不工作，请首先检查
板已初始化（红色F-LED应熄灭
所有I/O板）。请注意，如果出于某种原因
系统参数发生变化，红色LED可能亮起。
否则，红色LED可能指示I/O板
存在故障。同时检查电路板是否有24VDC电源
（内部或外部）。常见的错误源有
电缆故障、传感器故障等。
您可以使用示教器上的I/O菜单来
检查当前I/O板是否正常工作
正确地参见11章-输入和输出
程序如果已更换组合I/O DSQC 315配备16个
数字输入，16个数字输出（参见DSQC 223，页
2-17）和2个模拟输出1-10V（见DSQC 209，
2-19页）。参见数字I/O和模拟I/O规范
和提示。参见11章-输入和输出
程序模拟I/O板DSQC 209将模拟输入信号转换为数字信号，反之亦然。信号电平
等于10V输入和输出，分辨率为12位，包括字符。电路板内部或外部电压为±15V。电路板的模拟侧与系统电绝缘。输出是电流输出，可驱动或接通20 mA的电流。该电路板在前面板上有一个测试输入/输出和一个测试开关，可用于测试电路板是否正常工作。通过将测试开关转到测量输入的位置，可以将电源连接到测试端子
（系列中应使用保护电阻
通道）以测试输入是否正常工作。The combined I/O, DSQC 315, is equipped with 16
digital inputs, 16 digital outputs (see DSQC 223, page
2-17) and 2 analog outputs 1-10V (see DSQC 209,
page 2-19). See digital I/O and analog I/O specification
and tips. Refer to Chapter 11 - Inputs & Outputs for
procedure.The analog I/O board, DSQC 209, converts analognput signals to digital and vice versa. The signal level
equals 10V in and out with a resolution of 12 bitsincluding characters. The board is supplied with ±15V,either internally or externally. The analog side of theboard is galvanically insulated from the system. Theoutput, is the current output, which can drive or sinka current of 20 mA. The board has a test input/output onhe front panel and a test switch which can be used totest whether the board is working properly. By turningthe test switch to the position for measuring inputs, apower supply can be connected to the test terminal
(protecting resistance should be used in the serial
channel) to test whether the inputs are working properly.Turns ON when it receives ahigh signal from an input. TheLED shines more brightly themore voltage is input. Thismeans that even if the inputvoltage is just under thevoltage level “1”, the LED willglow dimly.OUTPUT Yellow Turns ON when a high signalis sent from an output. TheLED shines more brightly themore voltage is output.F Red Turns off when the boardapproves the Initialization.The digital input and output board, DSQC 223, has 16opto-isolated inputs and 16 opto-isolated outputs. Eachinput and output has its own yellow LED which indicates
whether or not the input/output is activated. The inputsand outputs normally receive their 24VDC supply from
a customer connection, but this can also be suppliedinternally (XS3/XT3 terminals A15,B15,A16,B16,C16.
If none of the I/O channels work, check first that the
boards are initialized (the red F-LED should be OFF on
all I/O boards). Note that if, for some reason, the
system's parameters change,
主营产品简介

专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。
发货期：1-3个工作日，具体可联系客服
质保：质保期一年！

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
