连接器应为带有陶瓷插头的卡口式。安装RXM机箱本程序介绍如何安装典型配置,其中包括位于主机箱附近的RXM机箱以及连接到此RXM机箱的其他RXM和扩展机箱。配置不能超过15个机箱。步骤1对于位于主机箱附近的RXM机箱,使用I/O总线电缆(型号9000)连接到每个机箱背板上的I/O总线连接器。底盘之间的长度不能超过100英尺(30米)。2在此RXM机箱中,在电源模块右侧立即安装主RXM套件(型号4200-3或4210-3)。根据需要安装I/O模块。主RXM集多可支持三个RXM或扩展机箱。要在一个Tricon控制器中设置三个以上的远程位置,请联系Triconex现场服务工程师。3对于远程位置的每个RXM机箱,安装远程RXM套件(型号4201-3或4211-3)。根据需要安装I/O模块。4使用光纤电缆将远程位置的每个RXM机箱与主机箱附近的RXM机箱连接,以连接到每个信道的发送和接收路径。
Connectors should be bayonet type with a ceramic tip plug. Installing an RXM Chassis This procedure explains how to install a typical configuration which includes an RXM Chassis located near the Main Chassis and additional RXM and Expansion Chassis connected to this RXM Chassis. The configuration cant exceed 15 chassis. Procedure 1 For the RXM Chassis located near the Main Chassis, use I/O bus cables (model 9000) to connect to the I/O Bus Connectors on the backplanes of each chassis. The length between the chassis cant exceed 100 feet (30 meters). 2 In this RXM Chassis, install a Primary RXM Set (model 4200-3 or 4210-3) immediately to the right of the Power Modules. Install I/O modules, as needed. The primary RXM Set can support up to three RXM or Expansion Chassis. To set up more than three remote locations in a single Tricon controller, please contact a Triconex Field Service Engineer. 3 For each RXM Chassis at a remote location, install Remote RXM Sets (model 4201-3 or 4211-3). Install I/O modules, as needed. 4 Connect each RXM Chassis at remote locations with the RXM Chassis located near the Main Chassis using fiber-optic cables to connect to the Transmit and Receive paths for each channel.
质保:质保期一年!
主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。
主营产品各种模块/卡件,控制器,触摸屏,伺服驱动器。
优势:供应进口原装正品,专业停产配件,
发货快,货期精准,
主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。
只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准,有任何疑问请联繁客服! Limited stock, Contact US!
