ICS T8850系统备件

产品详情资料

 此连接距离主底盘远可达7.5英里（12公里）。该接线图见图82。5根据需要安装I/O模块。6根据需要在本地和远程位置添加扩展机箱。底盘之间的长度不能超过100英尺（30米）。7将远程RXM底盘接地。参见第208页控制器接地。警告在安装RXM模块期间和每次维护活动后，确保所有光纤ST®连接器完全就位并接合。由于来自不同制造商的ST连接器可能会出现mir变化，因此需要仔细检查以验证ST锁定机构是否正确接合。未能正确固定连接器可能导致Tricon控制器运行不可靠，并终导致错误的电厂跳闸。RXM机箱安装207 Tricon v9–v10系统RXM模块光纤布线规划和安装指南此图显示了主RXM集合和远程RXM集合之间的布线，该集合将每个信道的接收（RX）连接到发送（TX）。This connection can be as far as 7.5 miles (12 kilometers) from the Main Chassis. See Figure 82 for a diagram of this wiring. 5 Install I/O modules, as needed. 6 Add Expansion Chassis as needed in both local and remote locations. The length between the chassis cant exceed 100 feet (30 meters). 7 Ground the remote RXM chassis. See Controller Grounding on page 208. WARNING During installation of RXM modules and after each maintenance activity, make sure that all fiber-optic ST® connectors are fully seated and engaged. Because ST connectors from different manufacturers may exhibit mir variations, close inspection is necessary to verify proper engagement of the ST locking mechanism. Failure to properly secure a connector could result in unreliable operation of the Tricon controller and could ultimately lead to a false plant trip. RXM Chassis Installation 207 Planning and Installation Guide for Tricon v9–v10 Systems Fiber-Optic Wiring for RXM Modules This figure shows the wiring between a primary RXM set and a remote RXM set, which connects a Receive (RX) to a Transmit (TX) for each channel.
