MAVS01L1AB0501D模块卡件

型号: MAVS01L1AB0501D  分类: foxboro
  • MAVS01L1AB0501D
  • MAVS01L1AB0501D
  • MAVS01L1AB0501D
  • MAVS01L1AB0501D
  • MAVS01L1AB0501D


产品详情资料

 可选地,您可以在Tricon控制器信号接地和专用仪器接地或DCS的公共连接点之间建立连接,如86所示。te要使用内部RC网络,请在每个Tricon电源模块上安装端子,模拟输入终端面板上的负(-)端子在Tricon内部连接。要连接到DCS主参考接地,请从所有Tricon电源模块上拆除默认跳线带。仅将主参考接地连接到Tricon主底盘上的信号接地端子,如果使用RXM底盘,则连接到每个远程位置的一个底盘上。TES隔离+24V电源RC+PS-+PS-模拟输入终端模拟输入终端控制器接地213 Tricon v9–v10系统的规划和安装指南将屏蔽连接到接地对于使用模拟模块的配置,电缆屏蔽应安装在电缆的一端,通常安装在现场设备上。如果必须使用控制器,则应使用外部屏蔽母线在终端面板附近提供连接。此类母线可从菲尼克斯电气或其他接线板供应商处获得。必须将每个屏蔽母线单独连接到适当的安静接地点,如专用接地或DCS主参考接地,如图所示。有关母线接线的详细信息,请参阅Tricon v9–v10系统现场终端指南,或联系IPS全球客户支持(GCS)中心。
Optionally, you can make a connection between the Tricon controller signal ground and a dedicated instrument ground or the common tie point of a DCS, as shown in 86. te To use the internal RC network, install the terminal on each Tricon Power Module and the minus (-) terminal on the Analog Input Termination Panel are internally connected in the Tricon. To connect to the DCS Master Reference Ground, remove the default jumper straps from all Tricon Power Supply modules. Connect the Master Reference Ground to the signal ground terminal on the Tricon Main Chassis only, and on one chassis at each remote location if RXM Chassis are used. TES Isolated +24V Power Supply RC + PS - + PS - Analog Input Termination Analog Input Termination Controller Grounding 213 Planning and Installation Guide for Tricon v9–v10 Systems Connecting Shields to Earth Ground For configurations that use analog modules, cable shields should be installed on one end of the cable, typically at the field device. If you must use the controller instead, you should provide a connection near the termination panel using an external shield bus bar. Such bus bars are available from Phoenix Contact or other terminal block suppliers. You must individually connect each shield bus bar to a suitable quiet ground point such as a dedicated earth ground or a DCS Master Reference Ground as shown in this . For details on bus bar wiring, see the Field Terminations Guide for Tricon v9–v10 Systems, or contact the IPS Global Client Support (GCS) center.
MAVS01L1AB0501D模块卡件

质保:质保期一年!



主营产品简介
专注于DCSPLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件,控制器,触摸屏,伺服驱动器。

优势:供应进口原装正品,专业停产配件,

发货快,货期精准,

主营品牌包括 ABB贝利、GE/FUANCFOXBORO、英维思TRICONEX 、本特利BENTLYA-B罗克韦尔、艾默生EMERSON OVATIONMOTOROLAXYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTHKUKANIDEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOGPROSOFT等品牌

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准,有任何疑问请联繁客服! Limited stock, Contact US!
