供应ABB PCD235B1101 3BHE032025R1101 库存模块

产品详情资料

C-1附录C I/O电缆数据表本附录提供了描述I/O系统中可使用的每种90-30系列电缆类型的数据表。这些数据表中的信息适用于由Series 90-30 PLC或安装有个人计算机接口卡的PC控制的I/O系统。本附录包含以下数据表：IC693CBL300/301/302/312/313/314–I/O总线扩展电缆IC693CBL 306/307–高密度I/O模块的扩展电缆（50针）用于高密度I/O模块的电缆（24针）IC693CBL321/322/323–用于高密度输入/输出模块的过时输入/输出电缆（24引脚）IC693C BL327/328–用于高浓度输入/输出模件的输入/输出接口电缆（24针脚IC693CBL300/301/302/312/313/314 I/O总线扩展电缆（包括构建定制长度电缆的说明）描述I/O总线扩展线缆（IC693CBL 300/301/3312313314），称为“Y形电缆”，一端有一个25针D连接器，另一端有两个25针（一个公头，一个母头）D连接器，如图（a）所示。50英尺（15米）（IC693CBL302）电缆在CPU底板端有一个单阳连接器，在扩展底板端有单端接阳连接器。3英尺电缆（IC693CBL300）也可用作WYE适配器电缆，以简化构建自定义长度电缆（请参阅本章后面的“电缆应用建议”一节）。a43853.5、3、6、26英尺电缆50英尺电缆母连接器公连接器公连接器连接器公连接器母连接器A B图B-1。I/O总线扩展电缆电缆长度IC693CBL300 3英尺（1米）、连续屏蔽IC693CBL 301 6英尺（2米）、持续屏蔽IC693C BL302或IC693CBL314 50英尺（15米）、，
C-1 Appendix C I/O Cable Data Sheets This appendix provides data sheets describing each of the Series 90-30 cable types that can be used in an I/O system. The information in these data sheets applies to I/O systems controlled by either a Series 90-30 PLC or by a PC with an installed Personal Computer Interface card. This appendix contains the following data sheets:  IC693CBL300/301/302/312/313/314 – I/O Bus Expansion cables  IC693CBL306/307 – Extension cables (50-pin) for high-density I/O modules  IC693CBL308/309 – I/O Interface cable (50-pin) for high-density I/O modules  IC693CBL310 – OBSOLETE I/O Interface cable (24–pin) for high density I/O modules  IC693CBL315 – OBSOLETE I/O Interface cable (24-pin) for high-density I/O modules  IC693CBL321/322/323 – OBSOLETE I/O cables (24–pin) for high–density I/O modules  IC693CBL327/328 – I/O Interface cables (24–pin) for high–density I/O modules  IC693CBL329/330/331/332/333/334 – I/O Interface cables (24–pin) for high–density I/O modules C C-2 Series 90-30 PLC I/O Module Specifications – July 2000 GFK-0898F IC693CBL300/301/302/312/313/314 I/O Bus Expansion Cables (Includes Instructions for Building Custom Length Cables) Description I/O bus expansion cables (IC693CBL300, 301, 312, 313, 314), called “Wye cables,” have a single male 25-pin D connector on one end and a two-headed (one male, one female) 25-pin D connector on the other end as shown in (A) of the figure. The 50 foot (15m) (IC693CBL302) cable has a single male connector on the CPU baseplate end and a single terminated male connector on the expansion baseplate end. The 3 foot cable (IC693CBL300) can also be used as a WYE adapter cable to simplify building custom length cables (see the section “Cable Application Suggestions” later in this Chapter). a43853 .5, 3, 6, 26 FOOT CABLES 50 FOOT CABLE FEMALE CONNECTOR MALE CONNECTOR MALE CONNECTOR MALE CONNECTOR MALE CONNECTOR A B Figure B-1. Detail of I/O Bus Expansion Cables Cable Lengths IC693CBL300 3 feet (1 meter), continuous shield IC693CBL301 6 feet (2 meters), continuous shield IC693CBL302 or IC693CBL314 50 feet (15 meters), continuous shield IC693CBL312 0.5 feet (0.15 meters),

发货期：1-3个工作日，具体可联系客服
质保：质保期一年！

主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
