供应 PM511V16 3BSE011181R1库存模块ABB

产品详情资料

 将电缆插入金属化盖中。分体式–环形卡套电缆护套地线连接至引脚1，用于定制长度电缆导线箔和编织物（折叠在卡套和地线上）a45524或折叠用于定制Y形电缆。**有关何时将加蔽线连接到引脚1的说明，请参阅“早期远程基板版本用户警报”。图B-2。如何为箔和编织电缆屏蔽使用开口环套圈对于典型的工业应用，所有扩展和远程底板电缆都可以用塑料外壳制成，并应按照图10-19所示进行接线。在任何一种情况下，引脚1都应连接到定制长度电缆的两端，远程（IC693CHS392/399）底板中的Y形电缆处理应遵循以下建议。当使用100%屏蔽电缆时，系统中的所有本地（CPU和扩展）底板必须牢固地参考同一接地点，否则底板之间的电位差可能会干扰信号传输。早期远程基板版本的用户警报在早期远程基板版IC693CHS393E（及更早版本）和IC693CHS 399D（及更早）中，有必要移除电缆插入基板的配合电缆的引脚1。这意味着，当使用工厂制造的Y形电缆（如IC693CBL300）时，必须在将引脚1与其中一个基板一起使用之前，将其从插入远程基板的阳端断开。这些底板的定制Y形电缆应使用图10-20制作。输入/输出电缆数据表C GFK-0898F附录C–输入/输出线缆数据表C-7远程基板IC693CHS393F（及更高版本）和IC693CHS 399E（及更新版本）在基板内部进行了更改，无需从配合线缆上拆下引脚1。当将工厂制造的Y形电缆与这些底板一起使用时，无需从电缆上拆下销1。这些底板的定制Y形电缆可以使用图
inserting the cable into a metallized cover. Split–Ring Ferrule Cable Jacket Ground Wire Attach to Pin 1 for custom length cables Conductors Foil & Braid (to be folded back over ferrule and ground wire) a45524 OR Fold back for custom Wye cables. * * See “Alert for Users of Early Remote Baseplate Versions” for description of when to attach drain wire to pin 1. Figure B-2. How to use Split-Ring Ferrules for Foil and Braided Cable Shield For typical industrial applications, all expansion and remote baseplate cables can be made with plastic shell covers and should be wired as shown in Figure 10-19. In either case, pin 1 should be wired into both ends of the custom length cable and the recommendations listed below should be followed for the Wye cables treatment in the remote (IC693CHS392/399) baseplates. When using 100% shielded cables all local (CPU and expansion) baseplates in the system must be solidly referenced to the same ground point or a potential difference between baseplates could disturb signal transmission. Alert for Users of Early Remote Baseplate Versions In early remote baseplates versions, IC693CHS393E (and earlier) and IC693CHS399D (and earlier), it is necessary to remove pin 1 of the mating cable where the cable plugs into the baseplate. This means that when using a factory made Wye cable, such as IC693CBL300, you must break pin 1 out of the male end where it plugs into the remote baseplate before using it with one of these baseplates. Custom built Wye cables for these baseplates should be built using Figure 10-20. I/O Cable Data Sheets C GFK-0898F Appendix C – I/O Cable Data Sheets C-7 Remote baseplates IC693CHS393F (and later) and IC693CHS399E (and later) have a change inside the baseplate which eliminates the need to remove pin 1 from the mating cable. When using factory made Wye cable with these baseplates, it is not necessary to remove pin 1 from the cable. Custom built Wye cables for these baseplates can be made using either Figure

发货期：1-3个工作日，具体可联系客服
质保：质保期一年！

主营产品简介
专注于DCS、PLC、机器人控制系统、大型伺服四大系统领域。

主营产品各种模块/卡件，控制器，触摸屏，伺服驱动器。

优势：供应进口原装正品，专业停产配件，

发货快，货期精准，

主营品牌包括 ABB贝利、GE/FUANC、FOXBORO、英维思TRICONEX 、本特利BENTLY、A-B罗克韦尔、艾默生EMERSON 、OVATION、MOTOROLA、XYVOM、霍尼韦尔HONEYWELL 、力士乐REXROTH、KUKA、NI、DEIF、横河、伍德沃德WOODWARD、瑞恩、施耐德SCHNEIDER 、安川、 穆格MOOG、PROSOFT等品牌。

只卖库存产品;出完需订货!价格以客服说明为准!!订货货期以客服说明为准，有任何疑问请联繁客服! Limited stock, Contact US!
