IEPU02计数器模块

a4683 0 20 0 32000 4至20 mA量程%AQ（十进制）电流（mA）a4684 0 20 0 3200 0至20 mA范围图12-3。电流输出电压操作的缩放对于默认单极模式（0至+10伏）下的电压操作，用户数据被缩放，使得0伏对应于0的计数，+10伏对应于32000的计数。在此模式下，您多可以输入32767，以获得大约10.24伏输出的超范围。在–10至+10伏范围内，用户数据被缩放，因此–10伏对应于–32000的计数，+10伏对应于+32000的计数。在此范围内，您可以输入–32768到+32767，以获得大约–10.24伏到+10.24伏的超范围。0至+10伏范围和–10至+10伏特范围的电压输出比例如下所示。%AQ（十进制）电压（V）0 a4658 10 10 32000 32000 0双极模式%AQ（十进制）电流（V）a45718 0 10 32000单极模式0图12-4。电压输出IC693ALG442模拟组合输入/输出模块的缩放12 GFK–0898F2章–IC693ALGA442a44683 0 20 0 32000 4 to 20 mA Range %AQ (decimal) CURRENT (mA) a44684 0 20 0 32000 0 to 20 mA Range Figure 12-3. Scaling for Current Output Voltage Operation For Voltage Operation in the default unipolar mode (0 to +10 volts), user data is scaled so that 0 volts corresponds to a count of 0 and +10 volts corresponds to a count of 32000. In this mode, you can enter up to 32767 for an overrange of approximately 10.24 volts output. In the –10 to +10 volt range user data is scaled so that –10 volts corresponds to a count of –32000 and +10 volts corresponds to a count of +32000. In this range, you can enter –32768 to +32767 for an overrange of approximately –10.24 volts to +10.24 volts. Scaling of the voltage output for both the 0 to +10 volt range and the –10 to +10 volt range is as shown below. %AQ (decimal) VOLTAGE (V) 0 a44658 10 10 32000 32000 0 Bipolar Mode %AQ (decimal) VOLTAGE (V) a45718 0 10 32000 Unipolar Mode 0 Figure 12-4. Scaling for Voltage Output IC693ALG442 Analog Combination I/O Module 12 GFK–0898F Chapter12 – IC693ALG442 )
