配置器功能，或使用GE Fanuc手持式编程器。下表描述了可配置的参数。使用Logicmaster 90-30/20/Micro编程软件和手持式编程器的组态程序如下页所述。表12-3。IC693ALG442的配置参数参数描述值当模块从RUN切换到STOP模式HOLD或DEFLOW HOLD N/A%AI ADR时，默认单位STOP模式输出状态%AI参考类型标准范围%AI0001的起始地址，或下一个高可用参考N/A%AQ ADR报警上限报警值的起始地址–32767至32760+32000用户计数有关模拟组合模块配置的详细信息，请参阅第3-93页开始的使用Logicmaster 90-30/20/Micro编程软件的配置。从第3-104页开始使用手持式编程器进行配置。IC693ALG442模拟组合I/O模块12 GFK–0898F2章–IC693ALGA442模拟混合I/O模块12-13使用Logicmaster软件配置IC693ALG442本节介绍如何使用Logicmaster 90-30/20/Micro编程软件中的配置器功能配置IC693A LG442模拟组合模块。也可以使用VersaPro或控制编程软件进行配置。
function, or with the GE Fanuc Hand-Held Programmer. The parameters that can be configured are described in the following table. Configuration procedures using Logicmaster 90-30/20/Micro Programming Software and the Hand-Held Programmer are described in the following pages. Table 12-3. Configuration Parameters for IC693ALG442 Parameter Description Values Defaults Units STOP MODE Output state when module toggled from RUN to STOP mode HOLD or DEFLOW HOLD N/A %AI ADR Starting address for the %AI reference type standard range %AI0001, or next highest available reference N/A %AQ ADR Starting address f ts ALARM HIGH High limit alarm value –32767 to 32760 +32000 User counts For detailed information on configuration of the Analog Combo module, see Configuration Using Logicmaster 90-30/20/Micro Programming Software beginning on page 3-93. Configuration Using the Hand-Held Programmer beginning on page 3-104. IC693ALG442 Analog Combination I/O Module 12 GFK–0898F Chapter12 – IC693ALG442 Analog Combination I/O Module 12-13 Configuring IC693ALG442 Using Logicmaster Software This section describes how to configure the IC693ALG442 Analog Combination module using the configurator function in Logicmaster 90-30/20/Micro Programming Software. Configuration can also be done using VersaPro or Control Programming Software.
