有关详细信息，请参阅VersaPro或Control联机帮助。要在I/O配置机架屏幕上配置模拟组合模块，请执行以下步骤：1。将光标移动到所需的机架和插槽位置。插槽可以是未配置的，也可以是以前配置的。2.按lm30 io键（F1）。您的屏幕将更改为与下面所示的屏幕类似的屏幕。3.在此屏幕上，按下混合键（F6）。您的屏幕将更改为与下面所示的屏幕类似的屏幕。12 12-14系列90–30 PLC I/O模块规格–2000年7月GFK–0898F 4。目前，只有一种选择。（如果出现多个选择，请使用光标移动（或箭头）键移动到目录#IC693ALG442。）按Enter键接受此选择并移动到下面显示的屏幕。5.不必在此屏幕上完成所有剩余配置。通过按光标移动（或箭头）键，可以将光标从一个字段移动到另一个字段。当您在要修改的字段中时，您可以键入您的选择或按Tab键滚动浏览可用的选择（或按Shift Tab键反转滚动方向）。注意：停止模式字段（HOLD或DEFLOW（DEFault LOW））中的条目决定了输出在以下情况下的行为For details refer to the VersaPro or Control online help. To configure an Analog Combo module on the I/O Configuration Rack screen, follow these steps: 1. Move the cursor to the desired rack and slot location. The slot may be either unconfigured or previously configured. 2. Press the lm30 io key (F1). Your screen will change to one similar to the one shown below. 3. From this screen, press the a mix key (F6). Your screen will change to one similar to the one shown below. 12 12-14 Series 90–30 PLC I/O Module Specifications – July 2000 GFK–0898F 4. Currently, there is only one selection. (If more than one selection appears, use your Cursor Movement (or Arrow) keys to move to Catalog # IC693ALG442.) Press Enter to accept this selection and to move to the screen shown below. 5. All the remaining configuration does not have to be done on this screen. You can move your cursor from field to field by pressing the Cursor Movement (or Arrow) keys. When you are in the field you want to modify, you can either type in your choice or press the Tab key to scroll through the available selections (or Shift-Tab to reverse the direction of the scrolling). Note The entry in the Stop Mode field (HOLD or DEFLOW (DEFault LOW)) determines how the outputs will behave when
