低于极限；1高于或=%I+14输入通道4报警LO-0指示值高于限值；1低于或=%I+15输入通道4警报高-0指示值低于极限；1以上或=第三个八个位置（可用于%I SIZE值24）%I位置描述%I+16输出通道#1断开电线0=正常，1=电线断开（仅限电流模式）%I+17输出通道#2断开电线0=正常，1=断线（仅限当前模式）%I+18到%I+23保留用于未来模块。本模块中未使用，可选择四个输入或输出范围中的一个；两个是电压范围。默认范围为0到+10V，其中输入或输出电压值范围为0至10伏。在输入模式下，它们向CPU报告0到32767的整数值，而在输出模式下，0和32767之间的值被发送到模块。在–10至+10V范围内，在–10到+10V的输入电压范围内，从CPU发送或接收–32768至32767之间的值。两个电流范围分别为4至20 mA和0至20 mA。在每个电流范围内，从模块返回0至32767之间的值以发送
below limit; 1 above or = %I+14 Input Ch #4 ALARM LO - 0 indicates value above limit; 1 below or = %I+15 Input Ch #4 ALARM HI - 0 indicates value below limit; 1 above or = The third eight locations (available for %I SIZE values 24) %I Locations Description %I+16 Output Ch #1 BROKEN WIRE 0 = OK, 1 = Wire Broken (Current modes only) %I+17 Output Ch #2 BROKEN WIRE 0 = OK, 1 = Wire Broken (Current modes only) %I+18 through %I+23 Reserved for future modules. Not used in this module One of four input or output ranges can be selected; two are voltage ranges. The default range is 0 to +10V, where input or output voltage values range from 0 to 10 volts. In input mode they report 0 to 32767 integer values to the CPU and in output mode values between 0 and 32767 are sent to the module. In the –10 to +10V range, values between –32768 to 32767 are sent or received from the CPU over an input voltage range of –10 to +10V. The two current ranges are 4 to 20 mA, and 0 to 20 mA. In each of the current ranges, values between 0 and 32767 are reported back from the module to sent
