不能作为单独的组件提供。项目描述电缆：仅Belden 8107（无替代品）：计算机电缆，整体编织箔屏蔽，双绞线30伏/80C（176F）24 AWG（.22 mm2）镀锡铜，7 x 32绞合传播速度=70%_x0005_标称阻抗=100Ω 25针公接头：压接插头=安培207464-1；引脚=Amp 66506-9焊接插头=Amp 747912-2 25针母连接器：压接插座=Amp 207463-2；引脚=Amp 66504-9焊料插座=Amp 747913-2连接器外壳：套件-Amp 745833-5：金属电镀塑料（铜上镀镍塑料）_x0005_压接环-Amp 747508-1，开口环套圈_x0005_=关键信息用户组装电缆的供应商零件号仅供参考，不建议或暗示。可以使用符合相同规格的任何零件。输入/输出电缆数据表C GFK-0898F附录C–输入/输出数据表C-5扩展端口引脚分配
is not available as a separate component. Item Description Cable: Belden 8107 only (no substitutes): Computer cable, overall braid over foil shield, twisted-pair 30 volt/80C (176F) 24 AWG (.22 mm2) tinned copper, 7 x 32 stranding Velocity of propagation = 70% _x0005_ Nominal impedance = 100Ω 25 Pin Male Connector: Crimp Plug = Amp 207464-1; Pin = Amp 66506-9 Solder Plug = Amp 747912-2 25 Pin Female Connector: Crimp Receptacle = Amp 207463-2; Pin = Amp 66504-9 Solder Receptacle = Amp 747913-2 Connector Shell: Kit - Amp 745833-5: Metal-plated plastic (plastic with nickel over copper) _x0005_ Crimp ring - Amp 745508-1, split ring ferrule _x0005_ = Critical Information Vendor part numbers listed for user assembled cables are provided for reference only and do not suggest or imply that they are preferred. Any part meeting the same specification can be used. I/O Cable Data Sheets C GFK-0898F Appendix C – I/O Cable Data Sheets C-5 Expansion Port Pin Assignments
